Classes
struct	function_exp
struct	function_const
struct	function_symbol
struct	symbol_table_entry
struct	symbol_table_entry_const
struct	template_parameter_range
Enumerations
enum	function_op { PLUS, MINUS, MUL, DIV, EXP, CONST, COS, SIN, TAN, LOG, ACOS, ASIN, ATAN, ABS, SQRT, DOT, CROSS, NEG, OR, AND, XOR, NOT, SYMBOL }
enum	function_datatype { INVALID = -1, BINARY, SCALAR, VECTOR2, VECTOR3 }
enum	symbol_type { CONSTANT_SYMBOL }
Functions
enum function_op	function_get_op_for_builtin_function (const char *bf)
void	function_print_tree (struct function_const e, GString *s, int indentation)
void	function_print_tree (struct function_symbol e, GString *s, int indentation)
void	function_print_tree (struct function_exp e, GString *s, int indentation)
GError *	evaluate_function (double value, const struct function_exp f, GHashTable global_symbols, GHashTable local_symbols)
enum function_datatype	get_function_datatype (struct function_exp f, GHashTable global_symbols, GHashTable *local_symbols)
struct symbol_table_entry *	get_symbol_table_entry (const char symbol, GHashTable global_symbols, GHashTable local_symbols, GError *e)
void	add_symbol_table_entry (GHashTable st, const char symbol, struct symbol_table_entry *entry)
static void	destroy_symbol_table_entry (void *ste_)
static void	destroy_symbol_table_symbol (void *symbol)
GHashTable *	new_symbol_table ()
void	parameter_list_init (GList *parameters)
bool	update_parameters_plus_check_if_done (GList *parameters)
GFile *	get_gfile_directory_for_template_state (const char prefix, GList parameters)
void	add_template_parameters_to_symbol_table (GHashTable st, GList parms)
char *	get_string_for_template_state (GList *parameters)
char *	get_header_for_template_state (GList *parameters)
void	free_function (struct function_const *e)
void	free_function (struct function_symbol *e)
void	free_function (struct function_exp *e)

Enumeration Type Documentation

enum kdotp::libmodelxx::postprocessing::function_datatype

Note that the data types correspond to 1-(the number of dimensions). This is a feature (take advantage of int conversion)

Enumerator:

INVALID
BINARY
SCALAR
VECTOR2
VECTOR3

Definition at line 61 of file function_specification.h++.

                             {
  INVALID=-1,
  BINARY,
  SCALAR,
  VECTOR2,
  VECTOR3
      };

enum kdotp::libmodelxx::postprocessing::function_op

Enumerator:

PLUS
MINUS
MUL
DIV
EXP
CONST
COS
SIN
TAN
LOG
ACOS
ASIN
ATAN
ABS
SQRT
DOT
CROSS
NEG
OR
AND
XOR
NOT
SYMBOL

Definition at line 34 of file function_specification.h++.

                       {
  PLUS,
  MINUS,
  MUL,
  DIV,
  EXP,
  CONST,
  COS,
  SIN,
  TAN,
  LOG,
  ACOS,
  ASIN,
  ATAN,
  ABS,
  SQRT,
  DOT,
  CROSS,
  NEG,
  OR,
  AND,
  XOR,
  NOT,
  SYMBOL
      };

enum kdotp::libmodelxx::postprocessing::symbol_type

Enumerator:

CONSTANT_SYMBOL

Definition at line 88 of file function_specification.h++.

                       {
  CONSTANT_SYMBOL
  //USER_FUNCTION
      };

Function Documentation

void kdotp::libmodelxx::postprocessing::add_symbol_table_entry	(	GHashTable *	st,
		const char *	symbol,
		struct symbol_table_entry *	entry
	)

Definition at line 580 of file function_specification.c++.

Referenced by kdotp::libmodelxx::grid::cartesian_grid< libmodelxx::structure::material *, 1, 1 >::cartesian_grid_init().

                                                                                                        {
  /*Copy the string*/
  GString* sb = g_string_new(symbol);
  g_hash_table_insert(st, sb->str, entry);
  g_string_free(sb, FALSE);
      }

Here is the caller graph for this function:

void kdotp::libmodelxx::postprocessing::add_template_parameters_to_symbol_table	(	GHashTable *	st,
		GList *	parms
	)

Definition at line 648 of file function_specification.c++.

References CONSTANT_SYMBOL, kdotp::libmodelxx::postprocessing::template_parameter_range::current_value, kdotp::libmodelxx::postprocessing::symbol_table_entry::dt, kdotp::libmodelxx::postprocessing::symbol_table_entry_const::dt, SCALAR, kdotp::libmodelxx::postprocessing::symbol_table_entry::st, kdotp::libmodelxx::postprocessing::symbol_table_entry_const::st, kdotp::libmodelxx::postprocessing::template_parameter_range::symbol, and kdotp::libmodelxx::postprocessing::symbol_table_entry_const::value.

Referenced by main().

                                                                                 {
  struct symbol_table_entry *ste;
  struct symbol_table_entry_const *stec=NULL;
  struct template_parameter_range *tpm;
  for(GList* ll=parms; ll!=NULL; ll=ll->next) {
    tpm = (struct template_parameter_range *)ll->data;
    ste = (struct symbol_table_entry*)g_hash_table_lookup(st, tpm->symbol);
    if(ste == NULL) {
      stec = (struct symbol_table_entry_const*)malloc(sizeof(struct symbol_table_entry_const));
      if(stec == NULL) {
        fprintf(stderr, "ERROR: unable to allocate new symbol table entry for symbol (%s)\n", tpm->symbol);
        continue;
      }
      stec->st = CONSTANT_SYMBOL;
      stec->dt = SCALAR;
      stec->value = (double*)malloc(sizeof(double));
      if(stec->value == NULL) {
        fprintf(stderr, "ERROR: unable to allocate new symbol table entry value storage for symbol (%s)\n", tpm->symbol);
        continue;
      }
      g_hash_table_insert(st, tpm->symbol, (struct symbol_table_entry*)stec);
    }else{
      if(ste->st != CONSTANT_SYMBOL) {
        fprintf(stderr, "ERROR:  symbol table entry for symbol (%s) is not a constant symbol (is %d)\n", tpm->symbol, stec->st);
        continue;
      }
      if(ste->dt != SCALAR) {
        fprintf(stderr, "ERROR:  symbol table entry for symbol (%s) is not a scalar type (is %d)\n", tpm->symbol, stec->dt);
        continue;
      }
      stec = (struct symbol_table_entry_const*)ste;
    }
    *(stec->value)=tpm->current_value;
  }
      }

Here is the caller graph for this function:

static void kdotp::libmodelxx::postprocessing::destroy_symbol_table_entry ( void * ste_ ) [static]

Definition at line 588 of file function_specification.c++.

References CONSTANT_SYMBOL, and kdotp::libmodelxx::postprocessing::symbol_table_entry::st.

Referenced by new_symbol_table().

                                                         {
  struct symbol_table_entry *ste = (struct symbol_table_entry *)ste_;
  switch(ste->st) {
  case CONSTANT_SYMBOL:
    free(((struct symbol_table_entry_const*)ste)->value);
    break;
  default:
    /*we can't communicate an error, so do no further processing*/
    ;
  }
  /*Finally, free the structure itself*/
  free((struct symbol_table_entry_const*)ste);
      }

Here is the caller graph for this function:

static void kdotp::libmodelxx::postprocessing::destroy_symbol_table_symbol ( void * symbol ) [static]

Definition at line 602 of file function_specification.c++.

Referenced by new_symbol_table().

                                                            {
  free(symbol);
      }

Here is the caller graph for this function:

GError * kdotp::libmodelxx::postprocessing::evaluate_function	(	double *	values,
		const struct function_exp *	f,
		GHashTable *	global_symbols,
		GHashTable *	local_symbols
	)

Evaluates a function using a set of symbol tables

Parameters:

values	array to store the results in
f	the function to be evaluated
global_symbols	the global symbol table (e.g. constants, built-in template parameters), user-defined template parameters
local_symbols	the local symbol table (e.g. x, X)

MUL and DIV can take scalar*vec

Definition at line 140 of file function_specification.c++.

References ABS, ACOS, AND, ASIN, ATAN, BINARY, CONST, CONSTANT_SYMBOL, COS, CROSS, DIV, DOT, kdotp::libmodelxx::postprocessing::symbol_table_entry::dt, kdp::constants::e, EXP, FUNCTION_SPECIFICATION_GERROR_DOMAIN, get_function_datatype(), get_symbol_table_entry(), INVALID, kdotp::libmodelxx::postprocessing::function_exp::l, LOG, MINUS, MUL, NEG, NOT, kdotp::libmodelxx::postprocessing::function_symbol::op, kdotp::libmodelxx::postprocessing::function_const::op, kdotp::libmodelxx::postprocessing::function_exp::op, OR, PLUS, kdotp::libmodelxx::postprocessing::function_exp::r, SCALAR, SIN, SQRT, kdotp::libmodelxx::postprocessing::symbol_table_entry::st, SYMBOL, TAN, and XOR.

Referenced by kdotp::libmodelxx::grid::cartesian_grid< libmodelxx::structure::material *, 1, 1 >::point_is_in_shape(), and kdotp::libmodelxx::grid::cartesian_grid< libmodelxx::structure::material *, 1, 1 >::set_point_function().

                                                                                                                                    {
  GError *err=NULL;
  GError *e=NULL;
  struct symbol_table_entry *ste;
  enum function_datatype lt=INVALID, rt=INVALID;
  double *l=NULL;
  double *r=NULL;
  /*Don't evaluate l & r if we're not actually a function_exp!!*/
  //fprintf(stderr, "carteisan_evaulate_function: op=%d", f->op);
  if((!((f->op == SYMBOL) ||(f->op == CONST))) && (f->l != NULL)) {
    lt = get_function_datatype(f->l, global_symbols, local_symbols);
    l = new double[lt];
    //fprintf(stderr, "\trecursing left\n");
    e = evaluate_function(l, f->l, global_symbols, local_symbols);
    if(e != NULL) {
      g_propagate_prefixed_error(&err, e, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: binary operator %d got error on left-hand side: ", f->op);
      delete[] l;
      return err;
    }
  } else {
    lt = INVALID;
    l = NULL;
  }
  /*Don't evaluate l & r if we're not actually a function_exp!!*/
  if((!((f->op == SYMBOL) ||(f->op == CONST))) && (f->r != NULL)) {
    rt = get_function_datatype(f->r, global_symbols, local_symbols);
    r = new double[rt];
    //fprintf(stderr, "\trecursing right\n");
    e = evaluate_function(r, f->r, global_symbols, local_symbols);
    if(e != NULL) {
      g_propagate_prefixed_error(&err, e, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: binary operator %d got error on right-hand side: ", f->op);
      if(l != NULL) delete[] l;
      delete[] r;
      return err;
    }
  } else {
    rt = INVALID;
    r = NULL;
  }
  /*
  fprintf(stderr, "carteisan_evaulate_function: lt=%d rt=%d op=%d", lt, rt, f->op);
  if(l != NULL) {
    fprintf(stderr, " l[0]=%g", l[0]);
  }else{
    fprintf(stderr, " l[0]=NULL");
  }
  if(r != NULL) {
    fprintf(stderr, " r[0]=%g", r[0]);
  }else{
    fprintf(stderr, " r[0]=NULL");
  }
  fprintf(stderr, "\n");
  */
  switch(f->op) {
  case PLUS:
  case MINUS:
  case MUL:
  case DIV:
    /**MUL and DIV can take scalar*vec*/
    if(!(
         ((f->op == MUL)&&((rt == 1) || (lt == 1)))
         ||((f->op == DIV)&&(rt==1))
         || (rt == lt)
         )) {
      if(l == NULL) delete[] l;
      if(r == NULL) delete[] r;
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 100, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with binary operation, left and right dimensions are not the same or a scalar * vec or vec */ scalar! (op=%d; l=%d, r=%d)", f->op, lt, rt);
    }
    if((rt < SCALAR) || (lt < SCALAR)) {
      if(l == NULL) delete[] l;
      if(r == NULL) delete[] r;
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 101, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with binary operation %d, arguments are invalid!", f->op);
    }
    /*Since we're iterating over rt, we need to iterate properly if
     *rt is 1 but lt isn't.
     */
    if((f->op == MUL) && (lt > rt)) {
      for(int i=0; i<lt; i++) {
        value[i] = l[i] * r[0];
        //fprintf(stderr, "rt*1: %g = %g*%g\n", value[i], l[i], r[i]);
      }
    }else if((f->op == DIV) && (lt > rt)) {
      for(int i=0; i<lt; i++) {
      value[i] = l[i] / r[0];
      //fprintf(stderr, "rt1/: %g = %g/%g\n", value[i], l[i], r[i]);
      }
    }else{
    for(int i=0; i<rt; i++) {
      switch(f->op) {
      case PLUS:
        value[i] = l[i] + r[i];
        //fprintf(stderr, "%g = %g+%g\n", value[i], l[i], r[i]);
        break;
      case MINUS:
        value[i] = l[i] - r[i];
        //fprintf(stderr, "%g = %g-%g\n", value[i], l[i], r[i]);
        break;
      case MUL:
        if(lt == 1) {
    value[i] = l[0] * r[i];
    //fprintf(stderr, "lt1*: %g = %g*%g\n", value[i], l[0], r[i]);
        }else{
    value[i] = l[i] * r[i];
    //fprintf(stderr, "*: %g = %g*%g\n", value[i], l[i], r[i]);
        }
        break;
      case DIV:
    value[i] = l[i] / r[i];
    //fprintf(stderr, "/: %g = %g/%g\n", value[i], l[i], r[i]);
        break;
      default:
        return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 107, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with binary operation %d, unhandled op-specific handling!", f->op);
      }
    }
    }
    break;
  case CONST:
    if(((struct function_const*)f)->value == NULL) {
      value[0] = 0;
      break;
    }
    if(((struct function_const*)f)->t == 0) {
      value[0] = ((struct function_const*)f)->value[0];
      break;
    }
    else for(int i=0; i<((struct function_const*)f)->t; i++) value[i] = ((struct function_const*)f)->value[i];
    //fprintf(stderr, "const: value[0]=%g\n", value[0]);
    break;
  case COS:
  case SIN:
  case TAN:
  case LOG:
  case EXP:
  case ACOS:
  case ASIN:
  case ATAN:
  case ABS:
  case SQRT:
    if(rt != 1) {
      if(l == NULL) delete[] l;
      if(r == NULL) delete[] r;
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 102, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with builtin function %d, argument dimension %d is not 1!", f->op, rt);
    }
    switch(f->op) {
    case COS:
      value[0] = cos(r[0]);
      //fprintf(stderr, "%g=cos(%g)\n", value[0], r[0]);
      break;
    case SIN:
      value[0] = sin(r[0]);
      //fprintf(stderr, "%g=sin(%g)\n", value[0], r[0]);
      break;
    case TAN:
      value[0] = tan(r[0]);
      //fprintf(stderr, "%g=tan(%g)\n", value[0], r[0]);
      break;
    case LOG:
      value[0] = log(r[0]);
      //fprintf(stderr, "%g=log(%g)\n", value[0], r[0]);
      break;
    case EXP:
      value[0] = ::exp(r[0]);
      //fprintf(stderr, "%g=exp(%g)\n", value[0], r[0]);
      break;
    case ACOS:
      value[0] = acos(r[0]);
      //fprintf(stderr, "%g=acos(%g)\n", value[0], r[0]);
      break;
    case ASIN:
      value[0] = asin(r[0]);
      //fprintf(stderr, "%g=asin(%g)\n", value[0], r[0]);
      break;
    case ATAN:
      value[0] = atan(r[0]);
      //fprintf(stderr, "%g=atan(%g)\n", value[0], r[0]);
      break;
    case ABS:
      value[0] = fabs(r[0]);
      //fprintf(stderr, "%g=abs(%g)\n", value[0], r[0]);
      break;
    case SQRT:
      value[0] = sqrt(r[0]);
      //fprintf(stderr, "%g=sqrt(%g)\n", value[0], r[0]);
      break;
    default:
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 107, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with builting function %d, unhandled op-specific handling!", f->op);
    }
    break;
  case DOT:
  case CROSS:
    /**MUL and DIV can take scalar*vec*/
    if(rt == lt) {
      if(l == NULL) delete[] l;
      if(r == NULL) delete[] r;
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 100, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with binary vector operation, left and right dimensions are not the same or a scalar * vec or vec */ scalar! (op=%d; l=%d, r=%d)", f->op, lt, rt);
    }
    if(rt < SCALAR) {
      if(l == NULL) delete[] l;
      if(r == NULL) delete[] r;
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 101, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with binary vector operation %d, arguments are invalid!", rt);
    }
    value[0] = 0;
    switch(f->op) {
    case DOT:
      for(int i=0; i<lt; i++) value[0] += l[i]*r[i];
      break;
    case CROSS:
      /*THIS NEEDS A CLEVER ALGO*/
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 101, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with binary vector operation %d, cross product is not yet implemented!", rt);
      break;
    default:
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 107, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with binary vector operation %d, unhandled op-specific handling!", f->op);
    }
    break;
  case postprocessing::OR:
  case postprocessing::AND:
  case postprocessing::XOR:
    if(rt == lt) {
      if(l == NULL) delete[] l;
      if(r == NULL) delete[] r;
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 100, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with binary binary operation, left and right dimensions are not the same scalar! (op=%d; l=%d, r=%d)", f->op, lt, rt);
    }
    if(rt != BINARY) {
      if(l == NULL) delete[] l;
      if(r == NULL) delete[] r;
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 101, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with binary binary operation %d, arguments are invalid!", rt);
    }
    switch(f->op) {
    case OR:
      value[0] = (l[0] || r[0]);
      break;
    case AND:
      value[0] = (l[0] && r[0]);
      break;
    case XOR:
      value[0] = ((l[0] || r[0]) && (!(l[0] && r[0])));
      break;
    default:
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 107, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with boolean binary operation %d, unhandled op-specific handling!", f->op);
    }
    break;
  case postprocessing::NOT:
    if(rt != BINARY) {
      if(l == NULL) delete[] l;
      if(r == NULL) delete[] r;
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 101, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with binary binary operation %d, arguments are invalid!", rt);
    }
    value[0] = !r[0];
    break;
  case SYMBOL:
    ste = get_symbol_table_entry(((struct function_symbol*)f)->symbol, global_symbols, local_symbols, &e);
    if((e != NULL) || (ste == NULL)) {
      if(e == NULL) {
        e = g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 100, "::kdotp::libmodelxx::function_specification.c++::evaluate_symbol: (%s) Unknown error looking up symbol in symbol tables.", (((struct function_symbol*)f)->symbol));
      }
      g_propagate_prefixed_error(&err, e, "::kdotp::libmodelxx::function_specification.c++::evaluate_symbol: (%s) Error looking up symbol in symbol tables.", (((struct function_symbol*)f)->symbol));
      return err;
    }
    switch(ste->st) {
    case CONSTANT_SYMBOL:
      for(int i=0; i<ste->dt; i++) {
        value[i]=((struct symbol_table_entry_const*)ste)->value[i];
      }
      break;
    default:
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 100, "::kdotp::libmodelxx::function_specification.c++::evaluate_symbol: (%s) Symbol is of unknown symbol type (%d).", (((struct function_symbol*)f)->symbol), ste->st);
    }
    //fprintf(stderr, "symbol %s: value[0]=%g\n", ((struct function_symbol*)f)->symbol, value[0]);
    break;
  case NEG:
    /*We can also negate a vector*/
    if(rt < 1) {
      return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 104, "::kdotp::libmodelxx::function_specification.c++::evaluate_function: with symbol (op NEG (%d)): right-hand side is not a valid number (scalar or higher-dimension)!", f->op);
    }
    for(int i=0; i<rt; i++) {
      value[i] = -r[i];
    }
    break;
  default:
    //fprintf(stderr, "Unknown op: %d\n", f->op);
    return g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 104, "WARNING: expression operator %d not implemented!", f->op);
  }
  //fprintf(stderr, "exiting op(%d)\n", f->op);
  return NULL;
      }

Here is the call graph for this function:

Here is the caller graph for this function:

void kdotp::libmodelxx::postprocessing::free_function ( struct function_const * e )

Definition at line 722 of file function_specification.c++.

References kdotp::libmodelxx::postprocessing::function_const::value.

Referenced by free_function(), and kdotp::libmodelxx::grid::shape_block_free().

                                                   {
  free(e->value);
  free(e);
      }

Here is the caller graph for this function:

void kdotp::libmodelxx::postprocessing::free_function ( struct function_symbol * e )

Definition at line 727 of file function_specification.c++.

References kdotp::libmodelxx::postprocessing::function_symbol::symbol.

                                                    {
  free(e->symbol);
  free(e);
      }

void kdotp::libmodelxx::postprocessing::free_function ( struct function_exp * e )

Definition at line 732 of file function_specification.c++.

References CONST, free_function(), kdotp::libmodelxx::postprocessing::function_exp::op, and SYMBOL.

                                                 {
  switch(e->op) {
  case CONST:
    free_function((struct function_const*)e);
    break;
  case SYMBOL:
    free_function((struct function_symbol*)e);
    break;
  default:
    if(e->l != NULL) free_function(e->l);
    if(e->r != NULL) free_function(e->r);
    free(e);
  }
      }

Here is the call graph for this function:

enum function_op kdotp::libmodelxx::postprocessing::function_get_op_for_builtin_function ( const char * c )

get a function

Parameters:

c	the builtin function to look up

Returns:: op corresponding to the function, or NOT if couldn't determine one

Definition at line 34 of file function_specification.c++.

References ABS, ACOS, ASIN, ATAN, COS, EXP, LOG, NOT, SIN, SQRT, and TAN.

Referenced by new_fx_func().

                                                                            {
        if(!g_ascii_strncasecmp("exp", bf, 3)) {
    return EXP;
  }else if(!g_ascii_strncasecmp("cos", bf, 3)) {
    return COS;
  }else if(!g_ascii_strncasecmp("sin", bf, 3)) {
    return SIN;
  }else if(!g_ascii_strncasecmp("tan", bf, 3)) {
    return TAN;
  }else if(!g_ascii_strncasecmp("acos", bf, 4)) {
    return ACOS;
  }else if(!g_ascii_strncasecmp("asin", bf, 4)) {
    return ASIN;
  }else if(!g_ascii_strncasecmp("atan", bf, 4)) {
    return ATAN;
  }else if(!g_ascii_strncasecmp("log", bf, 3)) {
    return LOG;
  }else if(!g_ascii_strncasecmp("abs", bf, 3)) {
    return ABS;
  }else if(!g_ascii_strncasecmp("sqrt", bf, 4)) {
    return SQRT;
  }else{
    return NOT;
  }
      }

Here is the caller graph for this function:

void kdotp::libmodelxx::postprocessing::function_print_tree	(	struct function_exp *	e,
		GString **	s,
		int	indentation
	)

Pretty prints a function tree to a sring you can print out. e the expression to print s a GString to which the output will be appended

Definition at line 72 of file function_specification.c++.

References ABS, ACOS, ASIN, ATAN, CONST, COS, CROSS, DIV, DOT, EXP, function_print_tree(), LOG, MINUS, MUL, NEG, kdotp::libmodelxx::postprocessing::function_symbol::op, kdotp::libmodelxx::postprocessing::function_exp::op, PLUS, SIN, SQRT, SYMBOL, and TAN.

                                                                                     {
  g_string_append_printf(*s, "\n%05d", indentation);
  for(int i=0; i<indentation; i++) {
    g_string_append_printf(*s, "%s", "\t");
  }
  if(e == NULL) {
    g_string_append_printf(*s, "%s", "[*]");
    return;
  }
  const char* funcname = NULL;
  switch(e->op) {
  case CONST:
    return function_print_tree((struct function_const*)e, s, indentation);
  case SYMBOL:
    return function_print_tree((struct function_symbol*)e, s, indentation);
  case EXP:
    funcname=(funcname==NULL)?"exp":funcname;
  case LOG:
    funcname=(funcname==NULL)?"log":funcname;
  case COS:
    funcname=(funcname==NULL)?"cos":funcname;
  case SIN:
    funcname=(funcname==NULL)?"sin":funcname;
  case TAN:
    funcname=(funcname==NULL)?"tan":funcname;
  case ACOS:
    funcname=(funcname==NULL)?"acos":funcname;
  case ASIN:
    funcname=(funcname==NULL)?"asin":funcname;
  case ATAN:
    funcname=(funcname==NULL)?"atan":funcname;
  case ABS:
    funcname=(funcname==NULL)?"abs":funcname;
  case SQRT:
    funcname=(funcname==NULL)?"sqrt":funcname;
  case NEG:
    funcname=(funcname==NULL)?"NEG":funcname;
    /*The above have just one argument:
     *NOTE that funcname will just be assigned once, when we jump in.
     */
    g_string_append_printf(*s, "%s", funcname);
    /*recurse!*/
    function_print_tree(e->l, s, indentation+1);
    return function_print_tree(e->r, s, indentation+1);
  case PLUS:
    funcname=(funcname==NULL)?"PLUS":funcname;
  case MINUS:
    funcname=(funcname==NULL)?"MINUS":funcname;
  case MUL:
    funcname=(funcname==NULL)?"MUL":funcname;
  case DIV:
    funcname=(funcname==NULL)?"DIV":funcname;
  case DOT:
    funcname=(funcname==NULL)?"DOT":funcname;
  case CROSS:
    funcname=(funcname==NULL)?"CROSS":funcname;
    g_string_append_printf(*s, "%s", funcname);
    /*recurse!*/
    function_print_tree(e->l, s, indentation+1);
    return function_print_tree(e->r, s, indentation+1);
  default:
    g_string_append_printf(*s, "[UNKNOWN OPERATION (%d)]", e->op);
    function_print_tree(e->l, s, indentation+1);
    return function_print_tree(e->r, s, indentation+1);
  }
  g_string_append_printf(*s, "%s", "[hit end of routine (coding error)]");
      }

Here is the call graph for this function:

void kdotp::libmodelxx::postprocessing::function_print_tree	(	struct function_const *	e,
		GString **	s,
		int	indentation
	)

Definition at line 60 of file function_specification.c++.

References kdotp::libmodelxx::postprocessing::function_const::t, and kdotp::libmodelxx::postprocessing::function_const::value.

Referenced by function_print_tree(), kdotp::libmodelxx::grid::make_block_from_shape(), kdotp::libmodelxx::continuous_structure::postprocess_structure(), and yyparse().

                                                                                       {
  g_string_append_printf(*s, "%s", "const(");
  for(int i=0; i<(e->t-1); i++) {
    g_string_append_printf(*s, "%g,", e->value[i]);
  }
  g_string_append_printf(*s, "%g)", e->value[e->t-1]);
      }

Here is the caller graph for this function:

void kdotp::libmodelxx::postprocessing::function_print_tree	(	struct function_symbol *	e,
		GString **	s,
		int	indentation
	)

Definition at line 68 of file function_specification.c++.

References kdotp::libmodelxx::postprocessing::function_symbol::symbol.

                                                                                        {
  g_string_append_printf(*s, "SYMBOL(%s)", e->symbol);
      }

enum function_datatype kdotp::libmodelxx::postprocessing::get_function_datatype	(	struct function_exp *	exp,
		GHashTable *	global_symbols,
		GHashTable *	local_symbols
	)

This gets the data type for the function

Parameters:

global_symbols	the global symbol table (e.g. constants, built-in template parameters), user-defined template parameters
local_symbols	the local symbol table (e.g. x, X)
exp	function

Definition at line 426 of file function_specification.c++.

References ABS, ACOS, AND, ASIN, ATAN, BINARY, CONST, COS, CROSS, DIV, DOT, kdotp::libmodelxx::postprocessing::symbol_table_entry::dt, kdp::constants::e, EXP, get_symbol_table_entry(), INVALID, kdotp::libmodelxx::postprocessing::function_exp::l, LOG, MINUS, MUL, NEG, NOT, kdotp::libmodelxx::postprocessing::function_symbol::op, kdotp::libmodelxx::postprocessing::function_exp::op, OR, PLUS, kdotp::libmodelxx::postprocessing::function_exp::r, SCALAR, SIN, SQRT, SYMBOL, TAN, and XOR.

Referenced by evaluate_function(), kdotp::libmodelxx::grid::cartesian_grid< libmodelxx::structure::material *, 1, 1 >::point_is_in_shape(), and kdotp::libmodelxx::grid::cartesian_grid< libmodelxx::structure::material *, 1, 1 >::set_point_function().

                                                                                                                                  {
  struct symbol_table_entry* ste;
  GError *e = NULL;
  enum function_datatype lt=INVALID, rt=INVALID;
  if(!((f->op == SYMBOL) || (f->op == CONST))) {
    if(f->l != NULL) lt = get_function_datatype(f->l, global_symbols, local_symbols);
    else lt = INVALID;
    if(f->r != NULL) rt = get_function_datatype(f->r, global_symbols, local_symbols);
    else lt = INVALID;
  }
  switch(f->op) {
  case PLUS:
  case MINUS:
    if(lt != rt) {
      //fprintf(stderr, "+-: lt!=rt: INVALID\n");
      return INVALID;
    }
    if(rt < 1) {
      //fprintf(stderr, "+-: rt<1: INVALID\n");
      return INVALID;
    }
    //fprintf(stderr, "+-: default (=rt=%d)\n", rt);
    return rt;
  case MUL:
    if((lt < 1) || (rt < 1)) {
      //fprintf(stderr, "*: lt||rt<1: INVALID\n");
      return INVALID;
    }
    if(lt == 1) {
      //fprintf(stderr, "*: lt==1: =rt=%d\n", rt);
      return rt;
    }
    if(rt == 1) {
      //fprintf(stderr, "*: rt==1: =lt=\n");
      return lt;
    }
    if(lt != rt) {
      //fprintf(stderr, "*: lt!=rt: INVALID\n");
      return INVALID;
    }
    //fprintf(stderr, "*: default (=rt=%d)\n", rt);
    return rt;
  case DIV:
    if((lt < 1) || (rt < 1)) {
      //fprintf(stderr, "/: lt||rt<1: INVALID\n");
      return INVALID;
    }
    if(rt == 1) {
      //fprintf(stderr, "/: rt==1: =lt=%d)\n", lt);
      return lt;
    }
    if(lt != rt) {
      //fprintf(stderr, "/: lt!=rt: INVALID\n");
      return INVALID;
    }
    //fprintf(stderr, "/: default (=rt=%d)\n", rt);
    return rt;
  case CONST:
    //fprintf(stderr, "CONST: exp has type %d\n", ((struct function_const*)f)->t);
    return ((struct function_const*)f)->t;
  case COS:
  case SIN:
  case TAN:
  case LOG:
  case EXP:
  case ACOS:
  case ASIN:
  case ATAN:
  case ABS:
  case SQRT:
    if(lt != INVALID) {
      //fprintf(stderr, "builtin_scalar_func: lt(=%d)!=INVALID: INVALID\n", lt);
      return INVALID;
    }
    if(rt != 1) {
      //fprintf(stderr, "builtin_scalar_func: rt(=%d)!=SCALAR: INVALID\n", rt);
      return INVALID;
    }
    //fprintf(stderr, "builtin_scalar_func: SCALAR\n");
    return SCALAR;
  case DOT:
    if((lt < 1) || (rt < 1)) {
      //fprintf(stderr, "DOT: lt||rt<1: INVALID\n");
      return INVALID;
    }
    //fprintf(stderr, "DOT: SCALAR");
    return SCALAR;
  case CROSS:
    if((lt < 1) || (rt < 1)) {
      //fprintf(stderr, "CROSS: lt||rt<1: INVALID\n");
      return INVALID;
    }
    if(lt != rt) {
      //fprintf(stderr, "CROSS: lt!=rt: INVALID\n");
      return INVALID;
    }
    //fprintf(stderr, "CROSS: default(=rt)\n");
    return rt;
  case postprocessing::OR:
  case postprocessing::AND:
  case postprocessing::XOR:
    if((lt != 0) || (rt != 0)) {
      //fprintf(stderr, "|&XOR: lt||rt!=0: INVALID\n");
      return INVALID;
    }
    //fprintf(stderr, "|&XOR: BINARY\n");
    return BINARY;
  case postprocessing::NOT:
    if(lt != INVALID) {
      //fprintf(stderr, "!: lt!=INVALID\n");
      return INVALID;
    }
    if(rt != 0) {
      //fprintf(stderr, "!: rt!=BINARY\n");
      return INVALID;
    }
    //fprintf(stderr, "!: BINARY\n");
    return BINARY;
  case SYMBOL:
    ste = get_symbol_table_entry(((struct function_symbol*)f)->symbol, global_symbols, local_symbols, &e);
    if((e != NULL) || (ste == NULL)) {
      return INVALID;
    }
    return ste->dt;
  case NEG:
    if(rt < 1) {
      //fprintf(stderr, "NEG: rt<1: INVALID\n");
      return INVALID;
    }
    //fprintf(stderr, "NEG: default (=rt=%d)\n", rt);
    return rt;
  default:
    fprintf(stderr, "UNRECOGNIZED OP(%d): INVALID\n", f->op);
    return INVALID;
  }
      }

Here is the call graph for this function:

Here is the caller graph for this function:

GFile * kdotp::libmodelxx::postprocessing::get_gfile_directory_for_template_state	(	const char *	prefix,
		GList *	parameters
	)

Definition at line 626 of file function_specification.c++.

Referenced by main().

                                                                                            {
  GString *s;
  if(prefix == NULL) {
    s = g_string_new("./");
  }else{
    s = g_string_new(prefix);
  }
  if(parameters != NULL) {
    s = g_string_append(s, ((struct template_parameter_range*)parameters->data)->symbol);
    g_string_append_printf(s, "=%g", ((struct template_parameter_range*)parameters->data)->current_value);
    /*We started with the first so that we can prefix the string with an underscore.*/
    if(parameters->next!=NULL) {
      for(GList* ll = parameters->next; ll!=NULL; ll=ll->next) {
        g_string_append_printf(s, "_%s=%g", ((struct template_parameter_range*)ll->data)->symbol, ((struct template_parameter_range*)ll->data)->current_value);
      }
    }
  }
  GFile *f = g_file_new_for_commandline_arg(s->str);
  g_string_free(s, TRUE);
  return f;
      }

Here is the caller graph for this function:

char * kdotp::libmodelxx::postprocessing::get_header_for_template_state ( GList * parameters )

Definition at line 703 of file function_specification.c++.

References str.

Referenced by main().

                                                             {
  GString *s = g_string_new("");
  if(parameters == NULL) {
    char *str = s->str;
    g_string_free(s, FALSE);
    return str;
  }
  s = g_string_append(s, ((struct template_parameter_range*)parameters->data)->symbol);
  /*We started with the first so that we can prefix the string with an underscore.*/
  if(parameters->next!=NULL) {
    for(GList* ll = parameters->next; ll!=NULL; ll=ll->next) {
      g_string_append_printf(s, "\t%s", ((struct template_parameter_range*)ll->data)->symbol);
    }
  }
  char *str = s->str;
  g_string_free(s, FALSE);
  return str;
      }

Here is the caller graph for this function:

char * kdotp::libmodelxx::postprocessing::get_string_for_template_state ( GList * parameters )

Definition at line 684 of file function_specification.c++.

References str.

Referenced by main().

                                                             {
  GString *s = g_string_new("");
  if(parameters == NULL) {
    char *str = s->str;
    g_string_free(s, FALSE);
    return str;
  }
  g_string_append_printf(s, "%g", ((struct template_parameter_range*)parameters->data)->current_value);
  /*We started with the first so that we can prefix the string with an underscore.*/
  if(parameters->next!=NULL) {
    for(GList* ll = parameters->next; ll!=NULL; ll=ll->next) {
      g_string_append_printf(s, "\t%g", ((struct template_parameter_range*)ll->data)->current_value);
    }
  }
  char *str = s->str;
  g_string_free(s, FALSE);
  return str;
      }

Here is the caller graph for this function:

struct symbol_table_entry * kdotp::libmodelxx::postprocessing::get_symbol_table_entry	(	const char *	symbol,
		GHashTable *	global_symbols,
		GHashTable *	local_symbols,
		GError **	e
	)		`[read]`

Definition at line 563 of file function_specification.c++.

References FUNCTION_SPECIFICATION_GERROR_DOMAIN.

Referenced by evaluate_function(), and get_function_datatype().

                                                                                                                                               {
  struct symbol_table_entry *ste_global = NULL;
  if(global_symbols != NULL) ste_global = (struct symbol_table_entry *)g_hash_table_lookup(global_symbols, symbol);
  struct symbol_table_entry *ste_local = NULL;
  if(local_symbols != NULL) ste_local = (struct symbol_table_entry *)g_hash_table_lookup(local_symbols, symbol);
  if((ste_global != NULL) && (ste_local != NULL)) {
    *e = g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 100, "::kdotp::libmodelxx::function_specification.c++::get_symbol_table_entry: symbol (%s) defined both locally and globally!", symbol);
    return NULL;
  }
  if((ste_global == NULL) && (ste_local == NULL)) {
    *e = g_error_new(FUNCTION_SPECIFICATION_GERROR_DOMAIN, 100, "::kdotp::libmodelxx::function_specification.c++::get_symbol_table_entry: symbol (%s) not defined.", symbol);
    return NULL;
  }
  if(ste_global != NULL) return ste_global;
  return ste_local;
      }

Here is the caller graph for this function:

GHashTable * kdotp::libmodelxx::postprocessing::new_symbol_table ( )

Definition at line 606 of file function_specification.c++.

References destroy_symbol_table_entry(), and destroy_symbol_table_symbol().

Referenced by kdotp::libmodelxx::grid::cartesian_grid< libmodelxx::structure::material *, 1, 1 >::cartesian_grid_init(), and main().

                                     {
  return (GHashTable*)g_hash_table_new_full(g_str_hash, g_str_equal, destroy_symbol_table_symbol, destroy_symbol_table_entry);
      }

Here is the call graph for this function:

Here is the caller graph for this function:

void kdotp::libmodelxx::postprocessing::parameter_list_init ( GList * parameters )

Definition at line 610 of file function_specification.c++.

Referenced by main().

                                                  {
  /*Initialize the loop over the template parameters*/
  for(GList* ll = parameters; ll!=NULL; ll=ll->next) ((struct template_parameter_range*)ll->data)->current_value = ((struct template_parameter_range*)ll->data)->from;
      }

Here is the caller graph for this function:

bool kdotp::libmodelxx::postprocessing::update_parameters_plus_check_if_done ( GList * parameters )

Definition at line 615 of file function_specification.c++.

Referenced by main().

                                                                   {
  for(GList* ll=parameters; ll!=NULL; ll=ll->next) {
    ((struct template_parameter_range*)ll->data)->current_value += ((struct template_parameter_range*)ll->data)->stepsize;
    if(((struct template_parameter_range*)ll->data)->current_value <= ((struct template_parameter_range*)ll->data)->to) return false;
    /*If we reach this point, the current value is greater than the stop value.  We need to reset this
     *  value and then loop around to the next value to increment.*/
    ((struct template_parameter_range*)ll->data)->current_value = ((struct template_parameter_range*)ll->data)->from;
  }
  return true;
      }

Here is the caller graph for this function:

kdotp::libmodelxx::postprocessing Namespace Reference

Classes

Enumerations

Functions

Enumeration Type Documentation

Function Documentation
