#include <libmodeling/bands.h>
Include dependency graph for wavefunction.h: This graph shows which files directly or indirectly include this file:Go to the source code of this file.
Classes | |
| struct | mstar_wavefunction_point_1d |
| struct | mstar_wavefunction_1d |
Functions | |
| struct mstar_wavefunction_1d * | mstar_wavefunction_1d_from_LAPACK_normlized (const struct mstar_wavefunction_1d *wf) |
| struct mstar_wavefunction_1d * | mstar_wavefunction_1d_new_gaussian (int N, double minx, double maxx, double sigma) |
| generate an effective mass wavefunc that's just a gaussian | |
| struct mstar_wavefunction_1d * | mstar_wavefunction_1d_new (int N) |
| allocate an effective mass wavefunction | |
| void | mstar_wavefunction_1d_free (struct mstar_wavefunction_1d *wf) |
| de-allocate an effective mass wavefunction | |
| void | mstar_wavefunction_1d_repack (const struct mstar_wavefunction_1d *wf, double **x, double **re, double **im, short int convert_lapack_to_density_normalization) |
| void mstar_wavefunction_1d_free | ( | struct mstar_wavefunction_1d * | wf | ) |
de-allocate an effective mass wavefunction
| wf | the wavefunction to be freed |
Definition at line 43 of file wavefunction.c.
References mstar_wavefunction_1d::points.
Referenced by avg_discrete_func_gaussian_1(), avg_discrete_func_gaussian_x(), convert_nextnano_mstar_wavefunction_to_general_1d(), and main().
{
free(wf->points);
free(wf);
}
Here is the caller graph for this function:| struct mstar_wavefunction_1d* mstar_wavefunction_1d_from_LAPACK_normlized | ( | const struct mstar_wavefunction_1d * | wf | ) | [read] |
Gets a wavefunction that's been normalized to *integrate* to 1.
| wf | a LAPACK-normalized wavefunction, that is, a wavefunction which *sums* to 1 (i.e. each point has been multiplied by the square root of the grid spacing) |
Definition at line 63 of file wavefunction.c.
References mstar_wavefunction_point_1d::im, mstar_wavefunction_1d::N, mstar_wavefunction_1d::points, mstar_wavefunction_point_1d::re, unlikely, and mstar_wavefunction_point_1d::x.
{
struct mstar_wavefunction_1d* nwf = (struct mstar_wavefunction_1d*)malloc(sizeof(struct mstar_wavefunction_1d));
if(nwf == NULL) return NULL;
nwf->N = wf->N;
nwf->points = (struct mstar_wavefunction_point_1d*)malloc(sizeof(struct mstar_wavefunction_point_1d)*nwf->N);
if(nwf->points == NULL) {
free(nwf);
return NULL;
}
/*handle crazy cases gracefully*/
if(unlikely(nwf->N < 3)) {
if(nwf->N == 2) {
nwf->points[0].x = wf->points[0].x;
nwf->points[0].re = wf->points[0].re/sqrt(wf->points[1].x-wf->points[0].x);
nwf->points[0].im = wf->points[0].im/sqrt(wf->points[1].x-wf->points[0].x);
nwf->points[1].x = wf->points[1].x;
nwf->points[1].re = wf->points[1].re/sqrt(wf->points[1].x-wf->points[0].x);
nwf->points[1].im = wf->points[1].im/sqrt(wf->points[1].x-wf->points[0].x);
}else{
nwf->points[0].x = wf->points[0].x;
nwf->points[0].re = wf->points[0].re;
nwf->points[0].im = wf->points[0].im;
}
}else{
/*Do average of forward and backward grid spaces, which necessitates special
* handling for the first and last points.*/
nwf->points[0].x = wf->points[0].x;
nwf->points[0].re = wf->points[0].re/sqrt(wf->points[1].x-wf->points[0].x);
nwf->points[0].im = wf->points[0].im/sqrt(wf->points[1].x-wf->points[0].x);
for(int i=1; i<(nwf->N-1); i++) {
nwf->points[i].x = wf->points[i].x;
nwf->points[i].re = wf->points[i].re/sqrt(0.5*(wf->points[i+1].x-wf->points[i-1].x));
nwf->points[i].im = wf->points[i].im/sqrt(0.5*(wf->points[i+1].x-wf->points[i-1].x));
}
nwf->points[nwf->N-1].x = wf->points[nwf->N-1].x;
nwf->points[nwf->N-1].re = wf->points[nwf->N-1].re/sqrt(wf->points[nwf->N-2].x-wf->points[nwf->N-1].x);
nwf->points[nwf->N-1].im = wf->points[nwf->N-1].im/sqrt(wf->points[nwf->N-2].x-wf->points[nwf->N-1].x);
}
return nwf;
}
| struct mstar_wavefunction_1d* mstar_wavefunction_1d_new | ( | int | N | ) | [read] |
allocate an effective mass wavefunction
| N | number of points in the wavefunc |
Definition at line 31 of file wavefunction.c.
References mstar_wavefunction_1d::N, mstar_wavefunction_1d::points, and unlikely.
Referenced by convert_nextnano_mstar_wavefunction_to_general_1d(), and mstar_wavefunction_1d_new_gaussian().
{
struct mstar_wavefunction_1d *wf = malloc(sizeof(struct mstar_wavefunction_1d));
if(unlikely(wf == NULL)) return NULL;
wf->points = malloc(N*sizeof(struct mstar_wavefunction_point_1d));
if(unlikely(wf->points == NULL)) {
free(wf);
return NULL;
}
wf->N = N;
return wf;
}
Here is the caller graph for this function:| struct mstar_wavefunction_1d* mstar_wavefunction_1d_new_gaussian | ( | int | N, |
| double | minx, | ||
| double | maxx, | ||
| double | sigma | ||
| ) | [read] |
generate an effective mass wavefunc that's just a gaussian
| N | number of points in the wavefunc |
| minx | minium x to evaluate at |
| maxx | maximum x to evaluate at |
| sigma | sigma to be used in evaluating the Gaußian |
Definition at line 49 of file wavefunction.c.
References mstar_wavefunction_1d_new(), mstar_wavefunction_1d::N, mstar_wavefunction_1d::points, and unlikely.
Referenced by avg_discrete_func_gaussian_1(), and avg_discrete_func_gaussian_x().
{
struct mstar_wavefunction_1d* wf = mstar_wavefunction_1d_new(N);
if(unlikely(wf == NULL)) return NULL;
double oosqrtsigma = 1.0/pow(sigma*M_PI, 0.25);
double oosigma = 1.0/(sigma*2);
for(int i=0; i<N; i++) {
double x = (maxx-minx)/N*i + minx;
(wf->points)[i].x = x;
(wf->points)[i].re = oosqrtsigma*exp(-x*x*oosigma);
(wf->points)[i].im = 0.0;
}
return wf;
}
Here is the call graph for this function: Here is the caller graph for this function:| void mstar_wavefunction_1d_repack | ( | const struct mstar_wavefunction_1d * | wf, |
| double ** | x, | ||
| double ** | re, | ||
| double ** | im, | ||
| short int | convert_lapack_to_density_normalization | ||
| ) |
Definition at line 104 of file wavefunction.c.
References mstar_wavefunction_point_1d::im, mstar_wavefunction_1d::N, mstar_wavefunction_1d::points, mstar_wavefunction_point_1d::re, unlikely, and mstar_wavefunction_point_1d::x.
Referenced by alpha_electric_term_mstar_nostrain(), alpha_from_del_psi2_nostrain(), alpha_interface_term_mstar_nostrain(), and average_discrete_function().
{
*x = malloc((wf->N)*sizeof(double));
*re = malloc((wf->N)*sizeof(double));
*im = malloc((wf->N)*sizeof(double));
if(convert_lapack_to_density_normalization) {
/*handle crazy cases gracefully*/
if(unlikely(wf->N < 3)) {
if(wf->N == 2) {
(*x)[0] = wf->points[0].x;
(*re)[0] = wf->points[0].re/sqrt(wf->points[1].x-wf->points[0].x);
(*im)[0] = wf->points[0].im/sqrt(wf->points[1].x-wf->points[0].x);
(*x)[1] = wf->points[1].x;
(*re)[1] = wf->points[1].re/sqrt(wf->points[1].x-wf->points[0].x);
(*im)[1] = wf->points[1].im/sqrt(wf->points[1].x-wf->points[0].x);
}else{
(*x)[0] = wf->points[0].x;
(*re)[0] = wf->points[0].re;
(*im)[0] = wf->points[0].im;
}
}else{
/*Do average of forward and backward grid spaces, which necessitates special
* handling for the first and last points.*/
(*x)[0] = wf->points[0].x;
(*re)[0] = wf->points[0].re/sqrt(wf->points[1].x-wf->points[0].x);
(*im)[0] = wf->points[0].im/sqrt(wf->points[1].x-wf->points[0].x);
for(int i=1; i<(wf->N-1); i++) {
(*x)[i] = wf->points[i].x;
(*re)[i] = wf->points[i].re/sqrt(0.5*(wf->points[i+1].x-wf->points[i-1].x));
(*im)[i] = wf->points[i].im/sqrt(0.5*(wf->points[i+1].x-wf->points[i-1].x));
}
(*x)[wf->N-1] = wf->points[wf->N-1].x;
(*re)[wf->N-1] = wf->points[wf->N-1].re/sqrt(wf->points[wf->N-1].x-wf->points[wf->N-2].x);
(*im)[wf->N-1] = wf->points[wf->N-1].im/sqrt(wf->points[wf->N-1].x-wf->points[wf->N-2].x);
}
}else{
for(int i=0; i<wf->N; i++) {
(*x)[i] = (wf->points)[i].x;
(*re)[i] = (wf->points)[i].re;
(*im)[i] = (wf->points)[i].im;
}
}
}
Here is the caller graph for this function:
