#include <gsl/gsl_errno.h>
#include <gsl/gsl_interp.h>
#include <gsl/gsl_spline.h>
#include <gsl/gsl_integration.h>
#include <math.h>
#include <libcommon/gimme-alpha_structs.h>
#include <libpostproccalx/alpha_calc.h>
#include <libmodeling/wavefunction.h>
#include <libcommon/gcc_hints.h>

Include dependency graph for alpha_calc.c:

Classes
struct	expectation_value_params
struct	integration_param
struct	integration_param_2
Defines
#define	MAX_GSL_INTEGRATION_INTERVALS 4096
Functions
__const double	InGaAs_Ep (double x)
___const double	AlInSb_gamma8_bandedge (float x)
___const double	AlInSb_gamma7_bandedge (float x)
___const double	AlInSb_Ep (float x)
___const double	complex_magnitude (double re, double im)
double	expectation_value_integrand0 (double x, void *params)
double	expectation_value_integrand1 (double x, void *params)
double	expectation_value_integrand2 (double x, void *params)
double	average_discrete_function (const double function, const double x, int N, const struct mstar_wavefunction_1d wf, short int derivative, double abserr, double relerr, double err)
	calculates the expectation value of func in state wf. ARGS:
double *	average_arrays (double *arrays[], int n_arrays, int array_size)
char *	find_left_right_of_iface (double iface, int prev, int next, double *x, int N)
double	alpha_interface_term_mstar_nostrain (const struct mstar_wavefunction_1d wf, const struct band hh_band, const struct band lh_band, const struct band so_band, const struct band cb_band, const struct potential potential, GList *ifs, double Ep)
__always_inline double	band_terms (double x, void *params)
double	integrand (double x, void *params)
__always_inline double	band_terms_del_psi2_method (double x, void *params)
__always_inline double	del_psi2 (double x, gsl_spline re, gsl_interp_accel re_accel, gsl_spline im, gsl_interp_accel im_accel)
double	integrand_del_psi2_method (double x, void *params)
double	alpha_electric_term_mstar_nostrain (const struct mstar_wavefunction_1d wf, const struct band hh_band, const struct band lh_band, const struct band so_band, const struct band cb_band, const struct potential potential, struct alpha_integrand_verificator vfp, double integration_error, double abserr, double relerr, gboolean no_integrate, double Ep)
double	alpha_from_del_psi2_nostrain (const struct mstar_wavefunction_1d wf, const struct band hh_band, const struct band lh_band, const struct band so_band, const struct band cb_band, const struct potential potential, struct alpha_integrand_verificator_2 vfp2, double integration_error, double abserr, double relerr, gboolean no_integrate, double Ep)
GError *	alpha_write_verificator_data (GFile f, const struct alpha_integrand_verificator vf)
GError *	alpha_write_verificator2_data (GFile f, const struct alpha_integrand_verificator_2 vf2)
void	alpha_free_verificator_data (struct alpha_integrand_verificator *vf)
void	alpha_free_verificator2_data (struct alpha_integrand_verificator_2 *vf2)
Variables
const double	hbar
const double	q_e
const double	oo_q_e
const double	m_e_0
const double	oo_m_e_0
const double	Ep_InSb = 23.3
const double	Ep_AlSb = 18.7
const double	Gamma8_edge_InSb = 23.3
const double	Gamma8_edge_AlSb = 18.7
const double	Gamma7_edge_InSb = 23.3
const double	Gamma7_edge_AlSb = 18.7
const double	Ep_InAs = 21.5
const double	Ep_GaAs = 28.8

Detailed Description

Definition in file alpha_calc.c.

Define Documentation

#define MAX_GSL_INTEGRATION_INTERVALS 4096

Definition at line 41 of file alpha_calc.c.

Referenced by alpha_electric_term_mstar_nostrain(), alpha_from_del_psi2_nostrain(), and average_discrete_function().

Function Documentation

___const double AlInSb_Ep ( float x )

Definition at line 80 of file alpha_calc.c.

References Ep_AlSb, and Ep_InSb.

                                   {
  return Ep_AlSb + (Ep_InSb - Ep_AlSb)*x;
}

___const double AlInSb_gamma7_bandedge ( float x )

Definition at line 76 of file alpha_calc.c.

References Gamma7_edge_AlSb, and Gamma7_edge_InSb.

                                                {
  return Gamma7_edge_AlSb + (Gamma7_edge_InSb - Gamma7_edge_AlSb)*x;
}

___const double AlInSb_gamma8_bandedge ( float x )

Definition at line 72 of file alpha_calc.c.

References Gamma8_edge_AlSb, and Gamma8_edge_InSb.

                                                {
  return Gamma8_edge_AlSb + (Gamma8_edge_InSb - Gamma8_edge_AlSb)*x;
}

double alpha_electric_term_mstar_nostrain	(	const struct mstar_wavefunction_1d *	wf,
		const struct band *	hh_band,
		const struct band *	lh_band,
		const struct band *	so_band,
		const struct band *	cb_band,
		const struct potential *	potential,
		struct alpha_integrand_verificator *	vfp,
		double *	integration_error,
		double	abserr,
		double	relerr,
		gboolean	no_integrate,
		double	Ep
	)

Definition at line 479 of file alpha_calc.c.

Referenced by main().

                                                                                                                                                                                                                                                                                                                                                                         {
  /*HH*/
  gsl_interp_accel *hh_acc = gsl_interp_accel_alloc();
  gsl_spline *hh = gsl_spline_alloc(gsl_interp_akima, hh_band->N);
  gsl_spline_init(hh, hh_band->x, hh_band->bandedge, hh_band->N);
  /*LH*/
  gsl_interp_accel *lh_acc = gsl_interp_accel_alloc();
  gsl_spline *lh = gsl_spline_alloc(gsl_interp_akima, lh_band->N);
  gsl_spline_init(lh, lh_band->x, lh_band->bandedge, lh_band->N);
  /*SO*/
  gsl_interp_accel *so_acc = gsl_interp_accel_alloc();
  gsl_spline *so = gsl_spline_alloc(gsl_interp_akima, so_band->N);
  gsl_spline_init(so, so_band->x, so_band->bandedge, so_band->N);
  /*CB*/
  gsl_interp_accel *cb_acc = gsl_interp_accel_alloc();
  gsl_spline *cb = gsl_spline_alloc(gsl_interp_akima, cb_band->N);
  gsl_spline_init(cb, cb_band->x, cb_band->bandedge, cb_band->N);
  /*Potential*/
  gsl_interp_accel *pot_acc = gsl_interp_accel_alloc();
  gsl_spline *pot = gsl_spline_alloc(gsl_interp_akima, potential->N);
  gsl_spline_init(pot, potential->x, potential->potential, potential->N);
  /*Get the average of the heavy and light holes for now*/
  double *arrays[] = {hh_band->bandedge, lh_band->bandedge};
  double *avg_array = average_arrays(arrays, 2, hh_band->N);
  gsl_interp_accel *avg_acc = gsl_interp_accel_alloc();
  gsl_spline *avg = gsl_spline_alloc(gsl_interp_akima, hh_band->N);
  gsl_spline_init(avg, hh_band->x, avg_array, hh_band->N);
  /*Wavefunction*/
  double* repacked_x;
  double* repacked_re;
  double* repacked_im;
  //for(unsigned i=0; i<wf->N; i++) fprintf(stderr, "wf.x=%g wf.re=%g\n", wf->points[i].x, wf->points[i].re);
  mstar_wavefunction_1d_repack(wf, &repacked_x, &repacked_re, &repacked_im, 1);
  //for(unsigned i=0; i<wf->N; i++) fprintf(stderr, "->repacked_x=%g repacked_re=%g\n", repacked_x[i], repacked_re[i]);
  gsl_interp_accel *re_acc = gsl_interp_accel_alloc();
  gsl_spline *re = gsl_spline_alloc(gsl_interp_akima, wf->N);
  gsl_spline_init(re, repacked_x, repacked_re, wf->N);
  gsl_interp_accel *im_acc = gsl_interp_accel_alloc();
  gsl_spline *im = gsl_spline_alloc(gsl_interp_akima, wf->N);
  gsl_spline_init(im, repacked_x, repacked_im, wf->N);
  /*DO THE INTEGRATION*/
  struct integration_param parms = {
    .re = re,
    .re_accel = re_acc,
    .im = im,
    .im_accel = im_acc,
    .hh = hh,
    .hh_accel = hh_acc,
    .lh = lh,
    .lh_accel = lh_acc,
    .so = so,
    .so_accel = so_acc,
    .cb = cb,
    .cb_accel = cb_acc,
    .avg = avg,
    .avg_accel = avg_acc,
    .pot = pot,
    .pot_accel = pot_acc,
  };
  gsl_function gsl_func = {
    .function = &integrand,
    .params = &parms
  };
  gsl_integration_workspace *w = gsl_integration_workspace_alloc(MAX_GSL_INTEGRATION_INTERVALS);
  double alpha;
  int status=0;
  if(!no_integrate) status = gsl_integration_qag(&gsl_func, repacked_x[0], repacked_x[wf->N-1], abserr, relerr, MAX_GSL_INTEGRATION_INTERVALS, GSL_INTEG_GAUSS61, w, &alpha, integration_error);
  if(status != 0) {
    fprintf(stderr, "alpha_electric_field_term_mstar_nostrain: ERROR occurred while integrating: %d (%s); returned %g w/error %g.  Retrying with GAUSS31\n", status, gsl_strerror(status), alpha, *integration_error);
    status = gsl_integration_qag(&gsl_func, repacked_x[0], repacked_x[wf->N-1], abserr, relerr, MAX_GSL_INTEGRATION_INTERVALS, GSL_INTEG_GAUSS31, w, &alpha, integration_error);
    if(status != 0) {
      fprintf(stderr, "\tFAILED: %d (%s); returned %g w/error %g   Retrying with GAUSS15\n", status, gsl_strerror(status), alpha, *integration_error);
      status = gsl_integration_qag(&gsl_func, repacked_x[0], repacked_x[wf->N-1], abserr, relerr, MAX_GSL_INTEGRATION_INTERVALS, GSL_INTEG_GAUSS15, w, &alpha, integration_error);
      if(status != 0) {
  size_t neval;
  fprintf(stderr, "\t\tFAILEd: %d (%s); returned %g w/error %g  Retrying with non-adaptive Gauss-Kronrod\n", status, gsl_strerror(status), alpha, *integration_error);
  status = gsl_integration_qng (&gsl_func, repacked_x[0], repacked_x[wf->N-1], abserr, relerr, &alpha, integration_error, &neval);
  if(status != 0) {
    fprintf(stderr, "\t\t\tFAILED : %d (%s); returned %g w/error %g (%ld evals)\n", status, gsl_strerror(status), alpha, *integration_error, (long int)neval);
  }else{
    fprintf(stderr, "\t\t\tSUCCESS: got %g w/error %g (%ld evals)\n", alpha, *integration_error, (long int)neval);
  }
      }else{
  fprintf(stderr, "\t\tSUCCESS: got %g w/error %g\n", alpha, *integration_error);
      }
    }else{
      fprintf(stderr, "\tSUCCESS: got %g w/error %g\n", alpha, *integration_error);
    }
  }
  gsl_integration_workspace_free(w);
  /*Save off the verification info, if needed.*/
  if(vfp != NULL) {
    vfp->N = 5000;
    vfp->x = malloc((vfp->N)*sizeof(double));
    vfp->prob_density = malloc((vfp->N)*sizeof(double));
    vfp->integrand = malloc((vfp->N)*sizeof(double));
    vfp->pot_deriv = malloc((vfp->N)*sizeof(double));
    vfp->pot = malloc((vfp->N)*sizeof(double));
    vfp->iface_equiv = malloc((vfp->N)*sizeof(double));
    vfp->sob = malloc((vfp->N)*sizeof(double));
    vfp->avg = malloc((vfp->N)*sizeof(double));
    vfp->oo_sob = malloc((vfp->N)*sizeof(double));
    vfp->oo_avg = malloc((vfp->N)*sizeof(double));
    for(int i=0; i<(vfp->N); i++) {
      (vfp->x)[i] = (potential->x)[0] + ((potential->x)[potential->N-1] - (potential->x)[0])/vfp->N*i;
      (vfp->integrand)[i] = integrand((vfp->x)[i], &parms);
      (vfp->prob_density)[i] = complex_magnitude(gsl_spline_eval(re, (vfp->x)[i], re_acc), gsl_spline_eval(im, (vfp->x)[i], im_acc));
      (vfp->pot_deriv)[i] = gsl_spline_eval_deriv(pot, (vfp->x)[i], pot_acc);
      (vfp->pot)[i] = gsl_spline_eval(pot, (vfp->x)[i], pot_acc);
      (vfp->iface_equiv)[i] = band_terms((vfp->x)[i], &parms);
      (vfp->sob)[i] = gsl_spline_eval(so, (vfp->x)[i], so_acc);
      (vfp->avg)[i] = gsl_spline_eval(avg, (vfp->x)[i], avg_acc);
      (vfp->oo_sob)[i] = 1.0/(vfp->sob)[i];
      (vfp->oo_avg)[i] = 1.0/(vfp->avg)[i];
    }
  }
  /*De-allocate structures.*/
  /*HH*/
  gsl_spline_free(hh);
  gsl_interp_accel_free(hh_acc);
  /*LH*/
  gsl_spline_free(lh);
  gsl_interp_accel_free(lh_acc);
  /*SO*/
  gsl_spline_free(so);
  gsl_interp_accel_free(so_acc);
  /*CB*/
  gsl_spline_free(cb);
  gsl_interp_accel_free(cb_acc);
  /*pot*/
  gsl_spline_free(pot);
  gsl_interp_accel_free(pot_acc);
  /*wavefunc*/
  gsl_spline_free(re);
  gsl_interp_accel_free(re_acc);
  /*HH*/
  gsl_spline_free(im);
  gsl_interp_accel_free(im_acc);
  free(repacked_x);
  free(repacked_re);
  free(repacked_im);
  free(avg);
  /*The factor of - is required to convert the volts to eV*/
  /*Don't forget to convert nm->m (from the wavefunction)*/
  *integration_error *= -hbar*hbar*Ep/6*oo_m_e_0*1e9;
  //alpha *= hbar*hbar*22/6*oo_m_e_0*1e9;
  alpha *= hbar*hbar*Ep/6*oo_m_e_0*1e9;
  return alpha;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void alpha_free_verificator2_data ( struct alpha_integrand_verificator_2 * vf2 )

frees the *data* in a verificator2. The struct itself is still kept (so you can point to a stack-allocated struct safely

Definition at line 863 of file alpha_calc.c.

References alpha_integrand_verificator_2::avg, alpha_integrand_verificator_2::band_term, alpha_integrand_verificator_2::d_prob_density, alpha_integrand_verificator_2::integrand, alpha_integrand_verificator_2::oo_avg, alpha_integrand_verificator_2::oo_sob, alpha_integrand_verificator_2::prob_density, alpha_integrand_verificator_2::sob, and alpha_integrand_verificator_2::x.

                                                                             {
  free(vf2->x);
  free(vf2->prob_density);
  free(vf2->d_prob_density);
  free(vf2->band_term);
  free(vf2->sob);
  free(vf2->avg);
  free(vf2->oo_sob);
  free(vf2->oo_avg);
  free(vf2->integrand);
}

void alpha_free_verificator_data ( struct alpha_integrand_verificator * vf )

frees the *data* in a verificator. The struct itself is still kept (so you can point to a stack-allocated struct safely

Definition at line 850 of file alpha_calc.c.

References alpha_integrand_verificator::avg, alpha_integrand_verificator::iface_equiv, alpha_integrand_verificator::integrand, alpha_integrand_verificator::oo_avg, alpha_integrand_verificator::oo_sob, alpha_integrand_verificator::pot, alpha_integrand_verificator::pot_deriv, alpha_integrand_verificator::prob_density, alpha_integrand_verificator::sob, and alpha_integrand_verificator::x.

                                                                         {
  free(vf->x);
  free(vf->prob_density);
  free(vf->integrand);
  free(vf->pot_deriv);
  free(vf->iface_equiv);
  free(vf->sob);
  free(vf->avg);
  free(vf->oo_sob);
  free(vf->oo_avg);
  free(vf->pot);
}

double alpha_from_del_psi2_nostrain	(	const struct mstar_wavefunction_1d *	wf,
		const struct band *	hh_band,
		const struct band *	lh_band,
		const struct band *	so_band,
		const struct band *	cb_band,
		const struct potential *	potential,
		struct alpha_integrand_verificator_2 *	vfp2,
		double *	integration_error,
		double	abserr,
		double	relerr,
		gboolean	no_integrate,
		double	Ep
	)

Definition at line 630 of file alpha_calc.c.

Referenced by main().

                                                                                                                                                                                                                                                                                                                                                                      {
  /*HH*/
  gsl_interp_accel *hh_acc = gsl_interp_accel_alloc();
  gsl_spline *hh = gsl_spline_alloc(gsl_interp_akima, hh_band->N);
  gsl_spline_init(hh, hh_band->x, hh_band->bandedge, hh_band->N);
  /*LH*/
  gsl_interp_accel *lh_acc = gsl_interp_accel_alloc();
  gsl_spline *lh = gsl_spline_alloc(gsl_interp_akima, lh_band->N);
  gsl_spline_init(lh, lh_band->x, lh_band->bandedge, lh_band->N);
  /*SO*/
  gsl_interp_accel *so_acc = gsl_interp_accel_alloc();
  gsl_spline *so = gsl_spline_alloc(gsl_interp_akima, so_band->N);
  gsl_spline_init(so, so_band->x, so_band->bandedge, so_band->N);
  /*CB*/
  gsl_interp_accel *cb_acc = gsl_interp_accel_alloc();
  gsl_spline *cb = gsl_spline_alloc(gsl_interp_akima, cb_band->N);
  gsl_spline_init(cb, cb_band->x, cb_band->bandedge, cb_band->N);
  /*Potential*/
  gsl_interp_accel *pot_acc = gsl_interp_accel_alloc();
  gsl_spline *pot = gsl_spline_alloc(gsl_interp_akima, potential->N);
  gsl_spline_init(pot, potential->x, potential->potential, potential->N);
  /*Get the average of the heavy and light holes for now*/
  double *arrays[] = {hh_band->bandedge, lh_band->bandedge};
  double *avg_array = average_arrays(arrays, 2, hh_band->N);
  gsl_interp_accel *avg_acc = gsl_interp_accel_alloc();
  gsl_spline *avg = gsl_spline_alloc(gsl_interp_akima, hh_band->N);
  gsl_spline_init(avg, hh_band->x, avg_array, hh_band->N);
  /*Wavefunction*/
  double* repacked_x;
  double* repacked_re;
  double* repacked_im;
  mstar_wavefunction_1d_repack(wf, &repacked_x, &repacked_re, &repacked_im, 1);
  gsl_interp_accel *re_acc = gsl_interp_accel_alloc();
  /*gsl_spline *re = gsl_spline_alloc(gsl_interp_cspline, wf->N);*/
  gsl_spline *re = gsl_spline_alloc(gsl_interp_akima, wf->N);
  gsl_spline_init(re, repacked_x, repacked_re, wf->N);
  gsl_interp_accel *im_acc = gsl_interp_accel_alloc();
  /*gsl_spline *im = gsl_spline_alloc(gsl_interp_cspline, wf->N);*/
  gsl_spline *im = gsl_spline_alloc(gsl_interp_akima, wf->N);
  gsl_spline_init(im, repacked_x, repacked_im, wf->N);
  /*DO THE INTEGRATION*/
  struct integration_param_2 parms = {
    .re = re,
    .re_accel = re_acc,
    .im = im,
    .im_accel = im_acc,
    .hh = hh,
    .hh_accel = hh_acc,
    .lh = lh,
    .lh_accel = lh_acc,
    .so = so,
    .so_accel = so_acc,
    .cb = cb,
    .cb_accel = cb_acc,
    .avg = avg,
    .avg_accel = avg_acc,
    .pot = pot,
    .pot_accel = pot_acc,
    .Ep = Ep,
    .Ep_z = NULL,
    .Ep_z_accel = NULL
  };
  gsl_function gsl_func = {
    .function = & integrand_del_psi2_method,
    .params = &parms
  };
  gsl_integration_workspace *w = gsl_integration_workspace_alloc(MAX_GSL_INTEGRATION_INTERVALS);
  double alpha;
  int status=0;
  if(!no_integrate) status = gsl_integration_qag(&gsl_func, repacked_x[0], repacked_x[wf->N-1], abserr, relerr, MAX_GSL_INTEGRATION_INTERVALS, GSL_INTEG_GAUSS61, w, &alpha, integration_error);
  if(status != 0) {
    fprintf(stderr, "alpha_calc::alpha_from_del_psi2_nostrain: ERROR occurred while integrating: %d (%s)\n", status, gsl_strerror(status));
  }
  gsl_integration_workspace_free(w);
  /*Save off the verification info, if needed.*/
  if(vfp2 != NULL) {
    vfp2->N = 5000;
    vfp2->x = malloc((vfp2->N)*sizeof(double));
    vfp2->prob_density = malloc((vfp2->N)*sizeof(double));
    vfp2->d_prob_density = malloc((vfp2->N)*sizeof(double));
    vfp2->integrand = malloc((vfp2->N)*sizeof(double));
    vfp2->sob = malloc((vfp2->N)*sizeof(double));
    vfp2->avg = malloc((vfp2->N)*sizeof(double));
    vfp2->oo_sob = malloc((vfp2->N)*sizeof(double));
    vfp2->oo_avg = malloc((vfp2->N)*sizeof(double));
    vfp2->band_term = malloc((vfp2->N)*sizeof(double));
    for(int i=0; i<(vfp2->N); i++) {
      (vfp2->x)[i] = (potential->x)[0] + ((potential->x)[potential->N-1] - (potential->x)[0])/vfp2->N*i;
      (vfp2->integrand)[i] = integrand_del_psi2_method((vfp2->x)[i], &parms);
      (vfp2->prob_density)[i] = complex_magnitude(gsl_spline_eval(re, (vfp2->x)[i], re_acc), gsl_spline_eval(im, (vfp2->x)[i], im_acc));
      (vfp2->d_prob_density)[i] = del_psi2((vfp2->x)[i], re, re_acc, im, im_acc);
      (vfp2->sob)[i] = gsl_spline_eval(so, (vfp2->x)[i], so_acc);
      (vfp2->avg)[i] = gsl_spline_eval(avg, (vfp2->x)[i], avg_acc);
      (vfp2->oo_sob)[i] = 1.0/(vfp2->sob)[i];
      (vfp2->oo_avg)[i] = 1.0/(vfp2->avg)[i];
      (vfp2->band_term)[i] = band_terms_del_psi2_method((vfp2->x)[i], &parms);
    }
  }
  /*De-allocate structures.*/
  /*HH*/
  gsl_spline_free(hh);
  gsl_interp_accel_free(hh_acc);
  /*LH*/
  gsl_spline_free(lh);
  gsl_interp_accel_free(lh_acc);
  /*SO*/
  gsl_spline_free(so);
  gsl_interp_accel_free(so_acc);
  /*CB*/
  gsl_spline_free(cb);
  gsl_interp_accel_free(cb_acc);
  /*pot*/
  gsl_spline_free(pot);
  gsl_interp_accel_free(pot_acc);
  /*wavefunc*/
  gsl_spline_free(re);
  gsl_interp_accel_free(re_acc);
  /*HH*/
  gsl_spline_free(im);
  gsl_interp_accel_free(im_acc);
  free(repacked_x);
  free(repacked_re);
  free(repacked_im);
  /*The factor of - is required to convert the volts to eV*/
  /*Don't forget to convert nm->m (from the wavefunction)*/
  *integration_error *= -hbar*hbar*6*oo_m_e_0*1e9;
  //alpha *= hbar*hbar*22/6*oo_m_e_0*1e9;
  alpha *= hbar*hbar*6*oo_m_e_0*1e9;
  return alpha;
}

Here is the call graph for this function:

Here is the caller graph for this function:

double alpha_interface_term_mstar_nostrain	(	const struct mstar_wavefunction_1d *	wf,
		const struct band *	hh_band,
		const struct band *	lh_band,
		const struct band *	so_band,
		const struct band *	cb_band,
		const struct potential *	potential,
		GList *	ifs,
		double	Ep
	)

Definition at line 262 of file alpha_calc.c.

References average_arrays(), band::bandedge, complex_magnitude(), find_left_right_of_iface(), hbar, expectation_value_params::im, m_e_0, mstar_wavefunction_1d_repack(), mstar_wavefunction_1d::N, potential::N, band::N, potential::potential, expectation_value_params::re, unlikely, potential::x, and band::x.

Referenced by main().

                                                                                                                                                                                                                                                             {
  double alpha = 0;
  int i=0;
  /*HH*/
  gsl_interp_accel *hh_acc = gsl_interp_accel_alloc();
  gsl_spline *hh = gsl_spline_alloc(gsl_interp_akima, hh_band->N);
  gsl_spline_init(hh, hh_band->x, hh_band->bandedge, hh_band->N);
  /*LH*/
  gsl_interp_accel *lh_acc = gsl_interp_accel_alloc();
  gsl_spline *lh = gsl_spline_alloc(gsl_interp_akima, lh_band->N);
  gsl_spline_init(lh, lh_band->x, lh_band->bandedge, lh_band->N);
  /*SO*/
  gsl_interp_accel *so_acc = gsl_interp_accel_alloc();
  gsl_spline *so = gsl_spline_alloc(gsl_interp_akima, so_band->N);
  gsl_spline_init(so, so_band->x, so_band->bandedge, so_band->N);
  /*CB*/
  gsl_interp_accel *cb_acc = gsl_interp_accel_alloc();
  gsl_spline *cb = gsl_spline_alloc(gsl_interp_akima, cb_band->N);
  gsl_spline_init(cb, cb_band->x, cb_band->bandedge, cb_band->N);
  /*Potential*/
  gsl_interp_accel *pot_acc = gsl_interp_accel_alloc();
  gsl_spline *pot = gsl_spline_alloc(gsl_interp_akima, potential->N);
  gsl_spline_init(pot, potential->x, potential->potential, potential->N);
  /*Wavefunction*/
  double *repacked_x;
  double *repacked_re;
  double *repacked_im;
  //for(unsigned i=0; i<wf->N; i++) fprintf(stderr, "wf.x=%g wf.re=%g\n", wf->points[i].x, wf->points[i].re);
  mstar_wavefunction_1d_repack(wf, &repacked_x, &repacked_re, &repacked_im, 1);
  //for(unsigned i=0; i<wf->N; i++) fprintf(stderr, "->repacked_x=%g repacked_re=%g\n", repacked_x[i], repacked_re[i]);
  gsl_interp_accel *re_acc = gsl_interp_accel_alloc();
  gsl_spline *re = gsl_spline_alloc(gsl_interp_akima, wf->N);
  gsl_spline_init(re, repacked_x, repacked_re, wf->N);
  gsl_interp_accel *im_acc = gsl_interp_accel_alloc();
  gsl_spline *im = gsl_spline_alloc(gsl_interp_akima, wf->N);
  gsl_spline_init(im, repacked_x, repacked_im, wf->N);
  /*Evaluate at the interfaces*/
  double *arrays[] = {hh_band->bandedge, lh_band->bandedge};
  double *avg = average_arrays(arrays, 2, hh_band->N);
  int prev=0, next=0;
  char* err;
  /*We don't need to keep track of the sign of the interface; that's
   *preserved from the definition of A and B; we just blindly use prev
   *and next; see epsilon_7^A and friends below for why*/
  double avg_p;
  double avg_n;
  double so_p;
  double so_n;
  double pot_p;
  double pot_n;
  /*the 0-point of energies reported in the printf below*/
  int zero_index_prev=0, zero_index_next=0;
  double relative_to;
  if(unlikely((err = find_left_right_of_iface(0, &zero_index_prev, &zero_index_next, hh_band->x, hh_band->N)) != NULL)) {
    fprintf(stderr, "WARNING: diagnostic print band structure is going to be relative to 0 (E_Fermi) (err=%s)\n", err);
    relative_to=0;
  }else{
    /*Average prev and next if there's no actual point at 0.*/
    if((zero_index_prev + 1) == zero_index_next) {
      relative_to = (((cb_band->bandedge)[zero_index_prev+1]) + ((cb_band->bandedge)[zero_index_prev+1]))*0.5;
    }else{
      relative_to = (cb_band->bandedge)[zero_index_prev+1];
    }
  }
  for(GList *i=g_list_first(ifs); i!=NULL; i=g_list_next(i)) {
    if(unlikely((err = find_left_right_of_iface(*((double*)(i->data)), &prev, &next, hh_band->x, hh_band->N)) != NULL)) {
      fprintf(stderr, "ERROR when getting prev/next indices for interface at %g: %s\n", *((double*)(i->data)), err);
      return -0;
    }
    /*
      epsilon_7^A is so_band->bandedge)[next]
      epsilon_7^B is (so_band->bandedge)[prev]
      epsilon_8^A is avg[prev]
      epsilon_8^B is avg[next]
      delta_7 = epsilon_7^B - epsilon_7^A
      = (so_band->bandedge)[next] - (so_band->bandedge)[prev]
      delta_8 = epsilon_8^B - epsilon_8^A
      = avg[next] - avg[prev]
      NOTE that the above have the potential still in them!
    */
    avg_p = avg[prev];
    avg_n = avg[next];
    so_p = (so_band->bandedge)[prev];
    so_n = (so_band->bandedge)[next];
    pot_p = (potential->potential)[prev];
    pot_n = (potential->potential)[next];
    //fprintf(stderr, "%g: d_avg=%g d_so=%g avg_n=%g avg_p=%g so_n=%g so_p=%g pot_n=%g pot_p=%g mag=%g (rel=%g)\n", *((double*)(i->data)), ((avg_n+pot_n)-(avg_p+pot_p)), ((so_n+pot_n)-(so_p+pot_p)), (avg_n-relative_to), (avg_p-relative_to), (so_n-relative_to), (so_p-relative_to), (pot_n), (pot_p), complex_magnitude(gsl_spline_eval(re, *((double*)(i->data)), re_acc), gsl_spline_eval(im, *((double*)(i->data)), im_acc)), relative_to);
    alpha += complex_magnitude(gsl_spline_eval(re, *((double*)(i->data)), re_acc), gsl_spline_eval(im, *((double*)(i->data)), im_acc))
      *(
  ((so_n+pot_n)-(so_p+pot_p))*(1.0/((so_n)*(so_n))+1.0/((so_p)*(so_p)))
  -((avg_n+pot_n)-(avg_p+pot_p))*(1.0/((avg_n)*(avg_n))+1.0/((avg_p)*(avg_p)))
  );
  }
  /*De-allocate structures.*/
  /*HH*/
  gsl_spline_free(hh);
  gsl_interp_accel_free(hh_acc);
  /*LH*/
  gsl_spline_free(lh);
  gsl_interp_accel_free(lh_acc);
  /*SO*/
  gsl_spline_free(so);
  gsl_interp_accel_free(so_acc);
  /*CB*/
  gsl_spline_free(cb);
  gsl_interp_accel_free(cb_acc);
  /*pot*/
  gsl_spline_free(pot);
  gsl_interp_accel_free(pot_acc);
  /*wavefunc*/
  gsl_spline_free(re);
  gsl_interp_accel_free(re_acc);
  /*HH*/
  gsl_spline_free(im);
  gsl_interp_accel_free(im_acc);
  free(repacked_x);
  free(repacked_re);
  free(repacked_im);
  free(avg);
  /*NOTE that the one-half from the summation has been absorbed into here.*/
  /*NOTE that the minus sign comes from the definitions of
    delta_gamma_x and S_n.  See notebook on April 28, 2009*/
  /*Don't forget to convert nm->m (from the wavefunction)*/
  //alpha *= hbar*hbar*22/12/m_e_0*1e9;  /*22eV, from the paper*/
  alpha *= hbar*hbar*Ep/12/m_e_0*1e9;  /*22eV, from the paper*/
  return alpha;
}

Here is the call graph for this function:

Here is the caller graph for this function:

GError* alpha_write_verificator2_data	(	GFile *	f,
		const struct alpha_integrand_verificator_2 *	vf2
	)

Definition at line 805 of file alpha_calc.c.

References alpha_integrand_verificator_2::avg, alpha_integrand_verificator_2::band_term, alpha_integrand_verificator_2::d_prob_density, alpha_integrand_verificator_2::integrand, alpha_integrand_verificator_2::N, alpha_integrand_verificator_2::oo_avg, alpha_integrand_verificator_2::oo_sob, alpha_integrand_verificator_2::prob_density, alpha_integrand_verificator_2::sob, str, and alpha_integrand_verificator_2::x.

Referenced by main().

                                                                                                 {
  GError *gerror = NULL;
  GFileOutputStream *os = g_file_replace(f, NULL, FALSE, G_FILE_CREATE_NONE, NULL, &gerror);
  if(os == NULL) {
    GError *e = NULL;
    g_propagate_prefixed_error(&e, gerror, "ERROR when opening method 2 instrumentation file for writing");
    return e;
  }
  GString *str = g_string_new("");
  GDataOutputStream *gdos = g_data_output_stream_new((GOutputStream*)os);
  g_string_printf(str, "#x(nm)\tprob_density(1/nm)\td_dz prob_density\tintegrand(1/(ev^2 nm))\tsplit-off (eV)\taverged HH,LH (eV)\t1/split-off (1/eV)\t1/averaged (1/eV)\tband terms (1eV)\n");
  g_data_output_stream_put_string(gdos, str->str, NULL, &gerror);
  if(gerror != NULL) {
    GError *e = NULL;
    g_propagate_prefixed_error(&e, gerror, "ERROR when writing method 2 instrumentation file header");
    g_object_unref(os);
    g_object_unref(gdos);
    g_string_free(str, TRUE);
    return e;
  }
  int N;
  N = vf2->N;
  for(int i=0; i<N; i++) {
    g_string_printf(str, "%g\t%g\t%g\t%g\t%g\t%g\t%g\t%g\t%g\n", (vf2->x)[i], (vf2->prob_density)[i], (vf2->d_prob_density)[i], (vf2->integrand)[i], (vf2->sob)[i], (vf2->avg)[i], (vf2->oo_sob)[i], (vf2->oo_avg)[i], (vf2->band_term)[i]);
    g_data_output_stream_put_string(gdos, str->str, NULL, &gerror);
    if(gerror != NULL) {
      GError *e = NULL;
      g_propagate_prefixed_error(&e, gerror, "ERROR when writing method 2 instrumentation file header (Missing line would have been:%s)", str->str);
      g_object_unref(os);
      g_object_unref(gdos);
      g_string_free(str, TRUE);
      return e;
    }
  }
  g_output_stream_close(G_OUTPUT_STREAM(gdos), NULL, &gerror);
  if(gerror != NULL) {
    GError *e = NULL;
    g_propagate_prefixed_error(&e, gerror, "ERROR when closing method 2 instrumentation output stream.\n");
  }
  g_object_unref(gdos);
  g_object_unref(os);
  g_string_free(str, TRUE);
  return NULL;
}

Here is the caller graph for this function:

GError* alpha_write_verificator_data	(	GFile *	f,
		const struct alpha_integrand_verificator *	vf
	)

Definition at line 761 of file alpha_calc.c.

References alpha_integrand_verificator::avg, alpha_integrand_verificator::iface_equiv, alpha_integrand_verificator::integrand, alpha_integrand_verificator::N, alpha_integrand_verificator::oo_avg, alpha_integrand_verificator::oo_sob, alpha_integrand_verificator::pot, alpha_integrand_verificator::pot_deriv, alpha_integrand_verificator::prob_density, alpha_integrand_verificator::sob, str, and alpha_integrand_verificator::x.

Referenced by main().

                                                                                             {
  GError *gerror = NULL;
  GFileOutputStream *os = g_file_replace(f, NULL, FALSE, G_FILE_CREATE_NONE, NULL, &gerror);
  if(os == NULL) {
    GError *e = NULL;
    g_propagate_prefixed_error(&e, gerror, "ERROR when opening alpha_efield instrumentation file for writing");
    return e;
  }
  GString *str = g_string_new("");
  GDataOutputStream *gdos = g_data_output_stream_new((GOutputStream*)os);
  g_string_printf(str, "#x(nm)\tprob_density(1/nm)\tintegrand(1/(ev^2 nm))\tpot_deriv(v/nm)\tband_terms(1/ev^2)\tsplit-off (eV)\taverged HH,LH (eV)\t1/split-off (1/eV)\t1/averaged (1/eV)\tPotential (eV)\n");
  g_data_output_stream_put_string(gdos, str->str, NULL, &gerror);
  if(gerror != NULL) {
    GError *e = NULL;
    g_propagate_prefixed_error(&e, gerror, "ERROR when writing alpha_efield instrumentation file header");
    g_object_unref(os);
    g_object_unref(gdos);
    g_string_free(str, TRUE);
    return e;
  }
  int N;
  N = vf->N;
  for(int i=0; i<N; i++) {
    g_string_printf(str, "%g\t%g\t%g\t%g\t%g\t%g\t%g\t%g\t%g\t%g\n", (vf->x)[i], (vf->prob_density)[i], (vf->integrand)[i], (vf->pot_deriv)[i], (vf->iface_equiv)[i], (vf->sob)[i], (vf->avg)[i], (vf->oo_sob)[i], (vf->oo_avg)[i], (vf->pot)[i]);
    g_data_output_stream_put_string(gdos, str->str, NULL, &gerror);
    if(gerror != NULL) {
      GError *e = NULL;
      g_propagate_prefixed_error(&e, gerror, "ERROR when writing alpha_efield instrumentation file header (Missing line would have been:%s)", str->str);
      g_object_unref(os);
      g_object_unref(gdos);
      g_string_free(str, TRUE);
      return e;
    }
  }
  g_output_stream_close(G_OUTPUT_STREAM(gdos), NULL, &gerror);
  if(gerror != NULL) {
    GError *e = NULL;
    g_propagate_prefixed_error(&e, gerror, "ERROR when closing alpha_efield instrumentation output stream.\n");
  }
  g_object_unref(gdos);
  g_object_unref(os);
  g_string_free(str, TRUE);
  return NULL;
}

Here is the caller graph for this function:

double* average_arrays	(	double *	arrays[],
		int	n_arrays,
		int	array_size
	)

Averages n_arrays of array_size doubles.

Parameters:

arrays	pointer to an array of arrays of doubles
n_arrays	number of arrays given
array_size	the size of the arrays stored in arrays.

Definition at line 203 of file alpha_calc.c.

References unlikely.

Referenced by alpha_electric_term_mstar_nostrain(), alpha_from_del_psi2_nostrain(), alpha_interface_term_mstar_nostrain(), and check_average_arrays().

                                                                       {
  if(unlikely(arrays == NULL)) return NULL;
  double *avg = malloc(sizeof(double)*array_size);
  if(unlikely(avg == NULL)) return NULL;
  if(unlikely(n_arrays < 1)) {
    free(avg);
    return NULL;
  }
  register int i;
  for(i=0; i<array_size; i++) {
    avg[i] = (arrays[0])[i];
    //fprintf(stderr, "(arrays[0])[%d]=%g\tavg[%d]=%g\n", i, (arrays[0])[i], i, avg[i]);
  }
  for(i=1; i<n_arrays; i++) {
    for(int j=0; j<array_size; j++) {
      avg[j] += (arrays[i])[j];
      //fprintf(stderr, "(arrays[%d])[%d]=%g\tavg[%d]=%g\n", i, j, (arrays[i])[j], i, avg[j]);
    }
  }
  for(i=0; i<array_size; i++) {
    avg[i] /= n_arrays;
  }
  return avg;
}

Here is the caller graph for this function:

double average_discrete_function	(	const double *	function,
		const double *	x,
		int	N,
		const struct mstar_wavefunction_1d *	wf,
		short int	derivative,
		double	abserr,
		double	relerr,
		double *	err
	)

calculates the expectation value of func in state wf. ARGS:

Parameters:

function,:	array of N doubles containing the function. : array of N doubles containing the x points at which function was sampled
N,:	the numnber of points in discrete function function.
wf,:	pointer to an mstar_wavefunction_1d structure containing
derivative,:	which derivative, if any, to use in evaluating the function, e.g. derivative=1 -> find the expectation value of the first derivative of function in state wf.
abserr	largest acceptable absolute integration error (GSL)
relerr	largest acceptable relative integration error (GSL)
err	pointer to a double to store the value of the (GSL) estimated integration error. RETURNS: The expectation value of the derivative-th derivative of function in state wf. NOTE: function must ONLY be a function of x! NOTE: only up to second derivative is supported.

Definition at line 140 of file alpha_calc.c.

References expectation_value_integrand0(), expectation_value_integrand1(), expectation_value_integrand2(), expectation_value_params::func_accel, expectation_value_params::im, expectation_value_params::im_accel, MAX_GSL_INTEGRATION_INTERVALS, mstar_wavefunction_1d_repack(), mstar_wavefunction_1d::N, expectation_value_params::re, and expectation_value_params::re_accel.

Referenced by avg_discrete_func_gaussian_1(), avg_discrete_func_gaussian_x(), and main().

                                                                                                                                                                                          {
  gsl_interp_accel *func_accel = gsl_interp_accel_alloc();
  gsl_spline *func = gsl_spline_alloc(gsl_interp_akima, N);
  gsl_spline_init(func, x, function, N);
  /*Wavefunction*/
  double *repacked_x;
  double *repacked_re;
  double *repacked_im;
  mstar_wavefunction_1d_repack(wf, &repacked_x, &repacked_re, &repacked_im, 1);
  gsl_interp_accel *re_accel = gsl_interp_accel_alloc();
  gsl_spline *re = gsl_spline_alloc(gsl_interp_akima, wf->N);
  gsl_spline_init(re, repacked_x, repacked_re, wf->N);
  gsl_interp_accel *im_accel = gsl_interp_accel_alloc();
  gsl_spline *im = gsl_spline_alloc(gsl_interp_akima, wf->N);
  gsl_spline_init(im, repacked_x, repacked_im, wf->N);
  struct expectation_value_params expectation_value_params = {
    .re_accel = re_accel,
    .im_accel = im_accel,
    .func_accel = func_accel,
    .re = re,
    .im = im,
    .func = func
  };
  gsl_function gsl_func = {
    .function = &expectation_value_integrand0,
    .params = &expectation_value_params
  };
  double e_val;
  double status=0;
  gsl_integration_workspace *w = gsl_integration_workspace_alloc(MAX_GSL_INTEGRATION_INTERVALS);
  switch(derivative) {
  case 0:
    gsl_func.function = &expectation_value_integrand0;
    break;
  case 1:
    gsl_func.function = &expectation_value_integrand1;
    break;
  case 2:
    gsl_func.function = &expectation_value_integrand2;
    break;
  default:
    return nan("char-sequence");
  }
  /*Here's where we do the integration.*/
  status = gsl_integration_qag(&gsl_func, repacked_x[0], repacked_x[wf->N-1], abserr, relerr, MAX_GSL_INTEGRATION_INTERVALS, GSL_INTEG_GAUSS61, w, &e_val, err);
  gsl_spline_free(re);
  gsl_spline_free(im);
  gsl_spline_free(func);
  gsl_interp_accel_free(re_accel);
  gsl_interp_accel_free(im_accel);
  gsl_interp_accel_free(func_accel);
  free(repacked_x);
  free(repacked_re);
  free(repacked_im);
  return e_val;
}

Here is the call graph for this function:

Here is the caller graph for this function:

__always_inline double band_terms	(	double	x,
		void *	params
	)

Definition at line 438 of file alpha_calc.c.

Referenced by alpha_electric_term_mstar_nostrain(), and integrand().

                                                          {
  //register double pot = gsl_spline_eval(((struct integration_param*)params)->pot, x, ((struct integration_param*)params)->pot_accel);
  double avg = (gsl_spline_eval(((struct integration_param*)params)->avg, x, ((struct integration_param*)params)->avg_accel));
  double so = (gsl_spline_eval(((struct integration_param*)params)->so, x, ((struct integration_param*)params)->so_accel));
  return (1.0/(so*so) - 1.0/(avg*avg));
}

Here is the caller graph for this function:

__always_inline double band_terms_del_psi2_method	(	double	x,
		void *	params
	)

Definition at line 453 of file alpha_calc.c.

Referenced by alpha_from_del_psi2_nostrain(), and integrand_del_psi2_method().

                                                                          {
  //register double pot = gsl_spline_eval(((struct integration_param_2*)params)->pot, x, ((struct integration_param_2*)params)->pot_accel);
  double avg = (gsl_spline_eval(((struct integration_param_2*)params)->avg, x, ((struct integration_param_2*)params)->avg_accel));
  double so = (gsl_spline_eval(((struct integration_param_2*)params)->so, x, ((struct integration_param_2*)params)->so_accel));
  return (1.0/so - 1.0/avg);
}

Here is the caller graph for this function:

___const double complex_magnitude	(	double	re,
		double	im
	)

Definition at line 84 of file alpha_calc.c.

Referenced by alpha_electric_term_mstar_nostrain(), alpha_from_del_psi2_nostrain(), alpha_interface_term_mstar_nostrain(), expectation_value_integrand0(), expectation_value_integrand1(), and expectation_value_integrand2().

                                                        {
  return re*re + im*im;
}

Here is the caller graph for this function:

__always_inline double del_psi2	(	double	x,
		gsl_spline *	re,
		gsl_interp_accel *	re_accel,
		gsl_spline *	im,
		gsl_interp_accel *	im_accel
	)

Definition at line 461 of file alpha_calc.c.

Referenced by alpha_from_del_psi2_nostrain(), and integrand_del_psi2_method().

                                                                                                                                  {
  //fprintf(stderr, "%g: %g->%g %g->%g\n", x, gsl_spline_eval(re, x, re_accel), gsl_spline_eval_deriv(re, x, re_accel), gsl_spline_eval(im, x, im_accel), gsl_spline_eval_deriv(im, x, im_accel));
  return 2*(gsl_spline_eval(re, x, re_accel)*gsl_spline_eval_deriv(re, x, re_accel) + gsl_spline_eval(im, x, im_accel)*gsl_spline_eval_deriv(im, x, im_accel));
}

Here is the caller graph for this function:

double expectation_value_integrand0	(	double	x,
		void *	params
	)

Definition at line 102 of file alpha_calc.c.

References complex_magnitude().

Referenced by average_discrete_function().

                                                            {
  return complex_magnitude(
         gsl_spline_eval(((struct expectation_value_params*)params)->re, x, ((struct expectation_value_params*)params)->re_accel),
         gsl_spline_eval(((struct expectation_value_params*)params)->im, x, ((struct expectation_value_params*)params)->im_accel)
         )*gsl_spline_eval(((struct expectation_value_params*)params)->func, x, ((struct expectation_value_params*)params)->func_accel);
}

Here is the call graph for this function:

Here is the caller graph for this function:

double expectation_value_integrand1	(	double	x,
		void *	params
	)

Definition at line 108 of file alpha_calc.c.

References complex_magnitude().

Referenced by average_discrete_function().

                                                            {
  return complex_magnitude(
         gsl_spline_eval(((struct expectation_value_params*)params)->re, x, ((struct expectation_value_params*)params)->re_accel),
         gsl_spline_eval(((struct expectation_value_params*)params)->im, x, ((struct expectation_value_params*)params)->im_accel)
         )*gsl_spline_eval_deriv(((struct expectation_value_params*)params)->func, x, ((struct expectation_value_params*)params)->func_accel);
}

Here is the call graph for this function:

Here is the caller graph for this function:

double expectation_value_integrand2	(	double	x,
		void *	params
	)

Definition at line 114 of file alpha_calc.c.

References complex_magnitude().

Referenced by average_discrete_function().

                                                            {
  return complex_magnitude(
         gsl_spline_eval(((struct expectation_value_params*)params)->re, x, ((struct expectation_value_params*)params)->re_accel),
         gsl_spline_eval(((struct expectation_value_params*)params)->im, x, ((struct expectation_value_params*)params)->im_accel)
         )*gsl_spline_eval_deriv2(((struct expectation_value_params*)params)->func, x, ((struct expectation_value_params*)params)->func_accel);
}

Here is the call graph for this function:

Here is the caller graph for this function:

char* find_left_right_of_iface	(	double	iface,
		int *	prev,
		int *	next,
		double *	x,
		int	N
	)

Finds the points to the left and right of the specified interface

Parameters:

iface	interface point
prev	pointer to an int to store the index of the previous point
next	Same, but the next point
x	array of x values, assumed to be sorted from smallest to largest
N	number of points in the x array

Returns:: pointer to a string that contains an error message (NULL if succeeded)

Definition at line 236 of file alpha_calc.c.

References unlikely.

Referenced by alpha_interface_term_mstar_nostrain().

                                                                                     {
  register int i;
  for(i=0; i<N; i++) {
    if(x[i] >= iface) {
      *prev = i-1;
      if(x[i] == iface) {
  //fprintf(stderr, "=(p=%i, n=%i, %g==%g [%g < %g])\n", *prev, *next, x[i], iface, x[*prev], iface);
  *next = i+1;
      }else{
  //fprintf(stderr, ">(p=%i, n=%i, %g>%g [%g < %g])\n", *prev, *next, x[i], iface, x[*prev], iface);
  *next = i;
      }
      break;
    }
    //fprintf(stderr, ".");
  }
  if(unlikely((i == N) || (*prev < 0) || (*next >= N))) {
    //fprintf(stderr, "E\n");
    if(i == N) return "specified interface not in structure";
    if(*prev < 0) return "specified interface is the start of the structure";
    if(*next >= N) return "specified interface is the end of the structure";
  }
  return NULL;
}

Here is the caller graph for this function:

__const double InGaAs_Ep ( double x )

Definition at line 68 of file alpha_calc.c.

References Ep_GaAs, and Ep_InAs.

                                   {
  return Ep_GaAs + (Ep_InAs - Ep_GaAs)*x;
}

double integrand	(	double	x,
		void *	params
	)

Definition at line 446 of file alpha_calc.c.

References band_terms().

Referenced by alpha_electric_term_mstar_nostrain().

                                         {
  register double re = gsl_spline_eval(((struct integration_param*)params)->re, x, ((struct integration_param*)params)->re_accel);
  register double im = gsl_spline_eval(((struct integration_param*)params)->im, x, ((struct integration_param*)params)->im_accel);
  register double ef = gsl_spline_eval_deriv(((struct integration_param*)params)->pot, x, ((struct integration_param*)params)->pot_accel);
  return ef*(re*re + im*im)*band_terms(x, params);
}

Here is the call graph for this function:

Here is the caller graph for this function:

double integrand_del_psi2_method	(	double	x,
		void *	params
	)

Definition at line 467 of file alpha_calc.c.

References band_terms_del_psi2_method(), and del_psi2().

Referenced by alpha_from_del_psi2_nostrain().

                                                         {
  if(((struct integration_param_2*)params)->Ep_z == NULL) {
    return (((struct integration_param_2*)params)->Ep)
      *del_psi2(x, ((struct integration_param_2*)params)->re, ((struct integration_param_2*)params)->re_accel, ((struct integration_param_2*)params)->im, ((struct integration_param_2*)params)->im_accel)
      *band_terms_del_psi2_method(x, params);
  }else{
    return gsl_spline_eval(((struct integration_param_2*)params)->Ep_z, x, ((struct integration_param_2*)params)->Ep_z_accel)
      *del_psi2(x, ((struct integration_param_2*)params)->re, ((struct integration_param_2*)params)->re_accel, ((struct integration_param_2*)params)->im, ((struct integration_param_2*)params)->im_accel)
      *band_terms_del_psi2_method(x, params);
  }
}
