#include <glib-2.0/glib.h>

Include dependency graph for binary_data_common.h:

This graph shows which files directly or indirectly include this file:

Classes
struct	dotcode_data
struct	dotcode_array
struct	dotcode_vector
struct	dotcode_tensor
struct	dotcode_grid
Defines
#define	DOTCODE_INT_SIZE 4
#define	DOTCODE_FLOAT4_SIZE 4
#define	DOTCODE_FLOAT8_SIZE 8
Enumerations
enum	dotcode_type { DOTCODE_INVALID_TYPE = -1, DOTCODE_FLOAT8, DOTCODE_FLOAT4, DOTCODE_INT, DOTCODE_SSTRING, DOTCODE_VECTOR, DOTCODE_ARRAY, DOTCODE_TENSOR, DOTCODE_GRID }
Functions
enum dotcode_type	dotcode_type_from_string (const char *s)
char *	dotcode_string_from_type (enum dotcode_type t)
const char *	dotcode_string_from_type2 (enum dotcode_type t)
void	flip_endian (char *buffer, int bytes)
int	dotcode_get_tensor_index (const struct dotcode_tensor, unsigned int *index)
void	dotcode_free_type (enum dotcode_type t, void ptr, long unsigned int count, GError *err, gboolean free_struct)
void	dotcode_determine_templated_type (const char str, GList tlist, GError *err)

Define Documentation

#define DOTCODE_FLOAT4_SIZE 4

Definition at line 37 of file binary_data_common.h.

Referenced by dotcode_read_float4(), and dotcode_write_float4().

#define DOTCODE_FLOAT8_SIZE 8

Definition at line 38 of file binary_data_common.h.

Referenced by dotcode_read_float8(), and dotcode_write_float8().

#define DOTCODE_INT_SIZE 4

Definition at line 36 of file binary_data_common.h.

Referenced by dotcode_read_int(), and dotcode_write_int().

Enumeration Type Documentation

enum dotcode_type

Enumerator:

DOTCODE_INVALID_TYPE
DOTCODE_FLOAT8
DOTCODE_FLOAT4
DOTCODE_INT
DOTCODE_SSTRING
DOTCODE_VECTOR
DOTCODE_ARRAY
DOTCODE_TENSOR
DOTCODE_GRID

Definition at line 40 of file binary_data_common.h.

                  {
  DOTCODE_INVALID_TYPE = -1,
  DOTCODE_FLOAT8,
  DOTCODE_FLOAT4,
  DOTCODE_INT,
  DOTCODE_SSTRING,
  DOTCODE_VECTOR,
  DOTCODE_ARRAY,
  DOTCODE_TENSOR,
  DOTCODE_GRID
};

Function Documentation

void dotcode_determine_templated_type	(	const char *	str,
		GList **	tlist,
		GError **	err
	)

Appends the type containers in str into a GList of

Parameters:

str	string containing type template.
tlist	a pointer to a NULL-initialized GList pointer.
err	pointer to a NULL-initialized error pointer.

This is the front-end to the determine_templated_type_ function.

Parameters:

str	is the list
tlist	a pointer to an existing GList*, which will be set to NULL.
err	is a pointer to an existing NULL GError*

Note:: the tlist is a GList of pointers to dotcode_types, in order of occurrance. Thus, a GList of a, b, c means a templated with b, which is in turn templated with c.

Definition at line 226 of file binary_data_common.c.

References determine_templated_type_().

Referenced by dotcode_read_tensor(), and read_dotcode_generic_file().

                                                                                    {
  *tlist = NULL;
  /*Remove invalid chars; valid are alphanumeric, underscoe, and >; this will
    remove '>', but that's fine; we don't really want it.
   */
  char* dstr = g_strdup(str);
  g_strcanon(dstr, "abcdefghijklmnopqrstuvwxyzABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789_<", ' ');
  g_strchug(dstr);
  char** sstr = g_strsplit(dstr, "<", 2);
  determine_templated_type_(sstr[0], sstr[1], tlist, err);
  g_free(dstr);
  g_strfreev(sstr);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void dotcode_free_type	(	enum dotcode_type	t,
		void *	ptr,
		long unsigned int	count,
		GError **	err,
		gboolean	free_struct
	)

Definition at line 102 of file binary_data_common.c.

References dotcode_tensor::data, DOTCODE_ARRAY, DOTCODE_BINARY_DATA_COMMON_GERROR_DOMAN, DOTCODE_FLOAT4, DOTCODE_FLOAT8, dotcode_free_type(), DOTCODE_GRID, DOTCODE_INT, DOTCODE_SSTRING, dotcode_string_from_type2(), DOTCODE_TENSOR, DOTCODE_VECTOR, e, dotcode_tensor::indices, and dotcode_tensor::metadata.

Referenced by dotcode_free_type(), dotcode_grid_from_density(), dotcode_internal_read_gridspec(), dotcode_read_grid(), libdotcode_readwrite_suite_add_tests(), main(), read_dotcode_generic_file(), read_dotcode_typed_file(), and read_random_10x10x10_float8_grid().

                                                                                                                    {
  GError *e = NULL;
  /*If we have a buffer of a simple type, just free it.*/
  switch(t) {
  case DOTCODE_FLOAT8:
  case DOTCODE_FLOAT4:
  case DOTCODE_INT:
  case DOTCODE_SSTRING:
    free(ptr);
    return;
  default:
    break;
  }
  long unsigned int size = 1;
  for(long unsigned int i=0; i<count; i++) {
    /*Since these are freeing an array of actual structures (as
      opposed to an array of pointers to structures) we don't need to
      free the struct at the end.*/
    switch(t) {
    case DOTCODE_VECTOR:
      dotcode_free_type(((struct dotcode_vector*)ptr)->t,
      ((struct dotcode_vector*)ptr)->data,
      3,
      &e,
      FALSE);
      break;
    case DOTCODE_ARRAY:
      dotcode_free_type(((struct dotcode_array*)ptr)->t,
      ((struct dotcode_array*)ptr)->storage,
      (((struct dotcode_array*)ptr)->imax - ((struct dotcode_array*)ptr)->imax +1),
      &e,
      FALSE);
      break;
    case DOTCODE_TENSOR:
      /*need to know how many items there are, for the derived types
  (irrelevant for float, int)*/
      size = 1;
      for(long unsigned int j=0; j<((struct dotcode_tensor*)ptr)->Nd; j++)
       size*=((((struct dotcode_tensor*)ptr)->indices)[2*j+1]-(((struct dotcode_tensor*)ptr)->indices)[2*j]+1);
      /*need to know how many items there are*/
      dotcode_free_type(((struct dotcode_tensor*)ptr)->t,
      ((struct dotcode_tensor*)ptr)->data,
      size,
      &e,
      FALSE);
      free(((struct dotcode_tensor*)ptr)->indices);
      free(((struct dotcode_tensor*)ptr)->metadata);
      break;
    case DOTCODE_GRID:
      for(int i=0; i<3; i++) {
  dotcode_free_type(DOTCODE_ARRAY,
      ((struct dotcode_grid*)ptr)->gridsites[i],
      1,
      &e,
      TRUE);
      }
      dotcode_free_type(DOTCODE_TENSOR,
      ((struct dotcode_grid*)ptr)->data,
      1,
      &e,
      TRUE);
      break;
    default:
      *err = g_error_new(DOTCODE_BINARY_DATA_COMMON_GERROR_DOMAN, 1, "dotcode::binary_data_common::dotcode_free_type: Invalid type %d (%s)", t, dotcode_string_from_type2(t));
      return;
    }
    if(e != NULL) {
      g_propagate_prefixed_error(err, e, "dotcode::binary_data_common::dotcode_free_type: Failure when freeing type %d (%s)", t, dotcode_string_from_type2(t));
      return;
    }
  }
  if(free_struct) {
    switch(t) {
    case DOTCODE_VECTOR:
      free((struct dotcode_vector*)ptr);
      break;
    case DOTCODE_ARRAY:
      free((struct dotcode_array*)ptr);
      break;
    case DOTCODE_TENSOR:
      free((struct dotcode_tensor*)ptr);
      break;
    case DOTCODE_GRID:
      free((struct dotcode_grid*)ptr);
      break;
    default:
      break;
    }
  }
}

Here is the call graph for this function:

Here is the caller graph for this function:

int dotcode_get_tensor_index	(	const struct dotcode_tensor	,
		unsigned int *	index
	)

char* dotcode_string_from_type ( enum dotcode_type t )

Definition at line 58 of file binary_data_common.c.

References dotcode_string_from_type2().

Referenced by dotcode_write_array(), dotcode_write_tensor(), and main().

                                                    {
  const char* s = dotcode_string_from_type2(t);
  if(s == NULL) return NULL;
  return g_strdup(s);
}

Here is the call graph for this function:

Here is the caller graph for this function:

const char* dotcode_string_from_type2 ( enum dotcode_type t )

This one is nice for using for one-off situations, e.g. error strings

Definition at line 64 of file binary_data_common.c.

References DOTCODE_ARRAY, DOTCODE_FLOAT4, DOTCODE_FLOAT8, DOTCODE_GRID, DOTCODE_INT, DOTCODE_INVALID_TYPE, DOTCODE_SSTRING, DOTCODE_TENSOR, and DOTCODE_VECTOR.

Referenced by dotcode_free_type(), dotcode_read_generic(), dotcode_read_tensor(), dotcode_string_from_type(), dotcode_write_array(), dotcode_write_float4(), dotcode_write_float8(), dotcode_write_generic(), dotcode_write_grid(), dotcode_write_int(), dotcode_write_sstring(), dotcode_write_tensor(), dotcode_write_typed_file(), main(), read_dotcode_generic_file(), and read_dotcode_typed_file().

                                                           {
  switch(t) {
  case DOTCODE_FLOAT8:
    return g_strdup("float8");
  case DOTCODE_FLOAT4:
    return g_strdup("float4");
  case DOTCODE_INT:
    return g_strdup("int4");
  case DOTCODE_VECTOR:
    return g_strdup("Vector");
  case DOTCODE_ARRAY:
    return g_strdup("Array");
  case DOTCODE_TENSOR:
    return g_strdup("Tensor");
  case DOTCODE_GRID:
    return g_strdup("Grid");
  case DOTCODE_SSTRING:
    return g_strdup("SString");
  case DOTCODE_INVALID_TYPE:
    return g_strdup("INVALID TYPE");
  default:
    return NULL;
  }
  return NULL;
}

Here is the caller graph for this function:

enum dotcode_type dotcode_type_from_string ( const char * s )

Definition at line 35 of file binary_data_common.c.

References DOTCODE_ARRAY, DOTCODE_FLOAT4, DOTCODE_FLOAT8, DOTCODE_GRID, DOTCODE_INT, DOTCODE_INVALID_TYPE, DOTCODE_SSTRING, DOTCODE_TENSOR, and DOTCODE_VECTOR.

Referenced by determine_templated_type_().

                                                          {
  if(!g_ascii_strncasecmp(s, "float8", strlen("float8"))){
    return DOTCODE_FLOAT8;
  }else if(!g_ascii_strncasecmp(s, "float4", strlen("float4"))){
    return DOTCODE_FLOAT4;
  }else if(!g_ascii_strncasecmp(s, "int", strlen("int"))){
    return DOTCODE_INT;
  }else if(!g_ascii_strncasecmp(s, "int4", strlen("int4"))){
    return DOTCODE_INT;
  }else if(!g_ascii_strncasecmp(s, "Vector", strlen("Vector"))){
    return DOTCODE_VECTOR;
  }else if(!g_ascii_strncasecmp(s, "Array", strlen("Array"))){
    return DOTCODE_ARRAY;
  }else if(!g_ascii_strncasecmp(s, "Tensor", strlen("Tensor"))){
    return DOTCODE_TENSOR;
  }else if(!g_ascii_strncasecmp(s, "Grid", strlen("Grid"))){
    return DOTCODE_GRID;
  }else if(!g_ascii_strncasecmp(s, "SString", strlen("SString"))){
    return DOTCODE_SSTRING;
  }
  return DOTCODE_INVALID_TYPE;
}

Here is the caller graph for this function:

void flip_endian	(	char *	buffer,
		int	bytes
	)

Definition at line 90 of file binary_data_common.c.

References c.

Referenced by dotcode_read_float4(), dotcode_read_float8(), and dotcode_read_int().

                                              {
  int i, j;
  char c;
  int max = num_bytes >> 1;
  for(i=0, j=(num_bytes-1); i<max; ++i, --j) {
    c=buffer[i];
    buffer[i]=buffer[j];
    buffer[j]=c;
  }
}

Here is the caller graph for this function:
